HDMI, USB-C, USB A 3.2Gen1, RJ45, 100W
Key Features
- Effortless connection - connect multiple devices to your USB-C computer
- Sharp and clear - Extend or mirror to your 4K HDMI display
- Transfer data and charge your devices via USB-C with power delivery up to 100W
- Lightweight and compact, durable aluminum design for mobility and workstation optimization
- Gigabit ethernet connection provides up to 1Gbps transfer speed
Description
Easily add an HDMI display, extra USB ports and Gigabit Ethernet to your USB-C Alt Mode device with this USB-C Mini Dock from V7. Extend or mirror your display with the HDMI 2.0 port. Lightweight and portable – the adapter can support display resolutions up to 4K. The two USB A 3.2 Gen 1 ports provide 5Gbps data transmission and 1.5A downstream charging. The USB-C port transfers data at 5Gbps and charging with Power Delivery up to 100W (20V/5A) (85W for Device Charging). The Gigabit Ethernet port supports 10M/100M/1000M bandwidth and can be used for the Nintendo Switch. Comes with a 2 year warranty. All V7 adapters go through a rigorous testing process to ensure quality.
Specifications
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
2 |
| Host interface |
USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI ports quantity |
1 |
| HDMI version |
2.0 |
| Connectivity technology |
Docking |
| USB Power Delivery |
Yes |
| USB Power Delivery up to |
100 W |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Performance |
|---|
| Maximum digital resolution |
3840 x 2160 pixels |
| Country of origin |
Vietnam |
| Product colour |
Black |
| Card reader integrated |
No |
| Data transfer rate |
5 Gbit/s |
| Technical details |
|---|
| Product colour |
Black |
| Data transfer rate |
5 Gbit/s |
| Harmonized System (HS) code |
84733020 |
| Storage |
|---|
| Card reader integrated |
No |
| Weight & dimensions |
|---|
| Weight |
620 g |
| Width |
22.9 mm |
| Depth |
134.3 mm |
| Height |
16.8 mm |
| Package weight |
660 g |
| Package width |
210 mm |
| Package depth |
160 mm |
| Package height |
16.3 mm |
| Design |
|---|
| Country of origin |
Vietnam |
| Product colour |
Black |
| Packaging data |
|---|
| Quantity per pack |
1 pc(s) |
| Package weight |
660 g |
| Package width |
210 mm |
| Package depth |
160 mm |
| Package height |
16.3 mm |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
| Logistics data |
|---|
| Harmonized System (HS) code |
84733020 |
