Description
6" 1080 x 2160, Qualcomm 6490 octa-core, 2.7 GHz, 4GB RAM/64GB UFS Flash, 802.11 a/b/g/n/ac/ax, Bluetooth 5.2, Android
The Ultimate in Rugged Design, Performance, Productivity and Ease of Use
The TC5X Series - the Wi-Fi only TC52x with Wi-Fi 5 (802.11ac), the Wi-Fi only TC52ax with Wi-Fi 6, and the Wi-Fi 5/cellular TC57x deliver the ultimate in rugged design, performance, and ease of use. The TC53/TC58, the new generation of the Zebra TC5X series mobile computers, is designed to do more with new hardware and software innovations that redefine mobile computing performance. No matter which models you choose, your workers get a user experience in a class of its own and all the latest technology advancements to work smarter — and faster.
Benefits of the TC5X Series
The Ultimate User Experience
The TC5X Series mobile computers have it all — from the familiarity of Android to the first-time every-time capture of barcodes, more Wi-Fi range and speed, video streaming, secure messaging, and the most powerful family of read-to-use voice solutions.
The Ultimate in Technology Advancements
You get maximum computing power to handle the apps of today and tomorrow, rich locationing support, more reliable Wi-Fi connections; high-quality voice; color cameras to capture ultra-high resolution photos and video intelligence and much more.
The Ultimate in Value-add Features
With Zebra’s powerful Mobility DNA suite, you get more value out of your mobile computers by adding functionality as well as simplifying deployment and management of your mobile devices, driving productivity and device control to a new level.
Description
TC5X Series Mobile ComputersThe Ultimate in Rugged Design, Performance, Productivity and Ease of Use
The TC5X Series - the Wi-Fi only TC52x with Wi-Fi 5 (802.11ac), the Wi-Fi only TC52ax with Wi-Fi 6, and the Wi-Fi 5/cellular TC57x deliver the ultimate in rugged design, performance, and ease of use. The TC53/TC58, the new generation of the Zebra TC5X series mobile computers, is designed to do more with new hardware and software innovations that redefine mobile computing performance. No matter which models you choose, your workers get a user experience in a class of its own and all the latest technology advancements to work smarter — and faster.
Benefits of the TC5X Series
The Ultimate User Experience
The TC5X Series mobile computers have it all — from the familiarity of Android to the first-time every-time capture of barcodes, more Wi-Fi range and speed, video streaming, secure messaging, and the most powerful family of read-to-use voice solutions.
The Ultimate in Technology Advancements
You get maximum computing power to handle the apps of today and tomorrow, rich locationing support, more reliable Wi-Fi connections; high-quality voice; color cameras to capture ultra-high resolution photos and video intelligence and much more.
The Ultimate in Value-add Features
With Zebra’s powerful Mobility DNA suite, you get more value out of your mobile computers by adding functionality as well as simplifying deployment and management of your mobile devices, driving productivity and device control to a new level.
Specifications
| Display | |
|---|---|
| Touchscreen type | Capacitive |
| Touch technology | Multi-touch |
| Touchscreen | Yes |
| Display resolution | 1080 x 2160 pixels |
| Display diagonal | 15.2 cm (6") |
| Display brightness | 600 cd/m² |
| Display glass type | Gorilla Glass |
| Memory | |
| Internal memory | 4 GB |
| Maximum memory card size | 2 TB |
| Compatible memory cards | MicroSD (TransFlash) |
| Flash memory | 64 GB |
| Processor | |
| Processor frequency | 2.7 GHz |
| Processor manufacturer | Qualcomm |
| Built-in processor | Yes |
| Network | |
| Near Field Communication (NFC) | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| Security algorithms | EAP-AKA, EAP-PWD, EAP-SIM, EAP-TLS, EAP-TTLS, LEAP, MSCHAPv2, WEP, WPA-Enterprise, WPA-TKIP, WPA2-AES, WPA2-Enterprise, WPA2-TKIP, WPA3-Enterprise, WPA3-SAE |
| Data network | 5G, LTE |
| Bluetooth version | 5.2 |
| Bluetooth | Yes |
| Wi-Fi | Yes |
| Bluetooth Low Energy (BLE) | Yes |
| SIM card type | NanoSIM |
| GPS Performance | |
| GLONASS | Yes |
| GPS (satellite) | Yes |
| Assisted GPS (A-GPS) | Yes |
| BeiDou | Yes |
| Galileo | Yes |
| Camera | |
| Video recording | Yes |
| Built-in flash | Yes |
| Built-in camera | Yes |
| Rear camera resolution (numeric) | 16 MP |
| Front camera | Yes |
| Front camera resolution (numeric) | 8 MP |
| Audio | |
| Speakers | stereo |
| Number of microphones | 3 |
| Noise-canceling | Yes |
| Ports & interfaces | |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Performance | |
| Barcode reader | Yes |
| Product colour | Black |
| Sensors | |
| Ambient light sensor | Yes |
| Accelerometer | Yes |
| Proximity sensor | Yes |
| Magnetometer | Yes |
| Gyroscope | Yes |
| Pressure sensor | Yes |
| Software | |
| Operating system installed | Android |
| Power | |
| Battery capacity | 4400 mAh |
| Battery technology | Lithium-Ion (Li-Ion) |
| Weight & dimensions | |
| Width | 77.3 mm |
| Depth | 16.8 mm |
| Height | 164.8 mm |
| Weight | 293 g |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -20 - 50 °C |
| Wireless LAN features | |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| Security algorithms | EAP-AKA, EAP-PWD, EAP-SIM, EAP-TLS, EAP-TTLS, LEAP, MSCHAPv2, WEP, WPA-Enterprise, WPA-TKIP, WPA2-AES, WPA2-Enterprise, WPA2-TKIP, WPA3-Enterprise, WPA3-SAE |
| Wi-Fi | Yes |
| Data transmission | |
| Data network | 5G, LTE |
| Bluetooth version | 5.2 |
| Bluetooth | Yes |
| Bluetooth Low Energy (BLE) | Yes |
| Technical details | |
| Barcode reader | Yes |
| Ambient light sensor | Yes |
| Accelerometer | Yes |
| Product colour | Black |
