Description
1D, CCD, 610-640nm, ≥4mil, USB, Black, 130g
The HR12 Anchoa can perform up to 300 scans per second, which translates into very fast and accurate barcode capturing. In addition, its compact size, ergonomic and solid state design makes a smart solution for extensive use in varied environments.
Description
The HR12 Anchoa handheld scanner is a practical & user friendly entry level scanner at an extremely competitive price. The Anchoa incorporates Newland's 1D chip technology for excellent 1D barcode scanning performance at exceptionally low power consumption.The HR12 Anchoa can perform up to 300 scans per second, which translates into very fast and accurate barcode capturing. In addition, its compact size, ergonomic and solid state design makes a smart solution for extensive use in varied environments.
Specifications
| Scanning | |
|---|---|
| Type | Handheld bar code reader |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, ITF-14, MSI |
| 2D (matrix & stacked) barcodes supported | Not supported |
| Yaw reading angle | -30 - 30° |
| Wavelength | 640 nm |
| Tilt reading angle | -60 - 60° |
| Sensor type | CCD |
| Scanner type | 1D |
| Read rate (max) | 300 reads/s |
| Pitch reading angle | -60 - 60° |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Cable length | 2 m |
| Standard interfaces | USB |
| Performance | |
| Protection features | Electrostatic Discharge (ESD) protection |
| LED indicators | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| Built-in processor | Yes |
| International Protection (IP) code | IP41 |
| Product colour | Black |
| Certification | FCC Part15 Class B, CE EMC Class B |
| Design | |
| Type | Handheld bar code reader |
| Protection features | Electrostatic Discharge (ESD) protection |
| LED indicators | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| International Protection (IP) code | IP41 |
| Product colour | Black |
| Certification | FCC Part15 Class B, CE EMC Class B |
| Power | |
| Power consumption | 120 mA |
| Power source type | DC |
| Weight & dimensions | |
| Width | 68.4 mm |
| Depth | 163 mm |
| Height | 58.5 mm |
| Weight | 130 g |
| Technical details | |
| Type | Handheld bar code reader |
| Protection features | Electrostatic Discharge (ESD) protection |
| LED indicators | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| Built-in processor | Yes |
| International Protection (IP) code | IP41 |
| Product colour | Black |
| Certification | FCC Part15 Class B, CE EMC Class B |
| Sustainability compliance | Yes |
| Warranty period | 5 year(s) |
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
| Packaging data | |
| Cables included | USB |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Packaging content | |
| Cables included | USB |
