Description
2.8”, 320x240, 1GB/8GB, 1.8 GHz, 24 keys, 1D/2D CMOS, BT, GPS, NFC, 4G, WiFi, USB, Android 8.1, 3300 mAh, 158 x 59 x 18.3 mm, 155 g
The special pre-installed DCAPP software allows customizing the MT37 Baiji to any solution you might require.
Light and Portable Data Collector
Made for high-demand operations, the MT37 Baiji provides a lightweight & ergonomic design to reduce fatigue during extended work sessions, and a long-lasting battery to get you through the entire shift without re-charging or switching out devices.
Superior Scanning Capabilities.
MT37 Baiji’s integrated 2D scan engine, equipped with Newland's 6th generation decoder chip, supports both 1D and 2D barcodes. The MT37 Baiji is set up to decode even damaged or poor-quality barcodes with ease and speed.
User-focused Ergonomics.
Made for high-demand operations, the MT37 Baiji renders a lightweight & ergonomic design to reduce fatigue during extended work sessions. The numeric keypad with some additional navigation buttons and a capacitive touch screen provides users with all the input choices they need.
Extended Battery Life.
The MT37 Baiji's 3300 mAh battery lasts up to 10 hours on a single charge. This enables you to get through your entire shift without re-charging or switching out devices.
Customized Android OS.
Built on Android 8.1 Go, the MT37 Baiji offers extended data security features, including Android's application protection and admin management tools.
Excellent Setup.
The MT37 Baiji is equipped with a Quad-Core processor, Android 8.1 Go OS, high-performance Dual-Band Wi-Fi, and Bluetooth 5.0 connection. Its rugged housing can withstand 1.2m drops to concrete.
DCAPP Software.
The MT37 Baiji comes with pre-installed and pre-licensed Newland DCAPP by Sysdev. Newland's DCAPP is a ready-to-use app that allows you to collect, transfer, and export data in a very simple way. With DCAPP, you can quickly start to collect data with 5 included pre-established templates of ready-to-be-used apps. It can then be synchronized with your PC or server to effortlessly export the gathered data.
Key Features
- Light and Portable Data Collector
- Superior Scanning Capabilities
- User-focused Ergonomics
- Extended Battery Life
- Customized Android OS
- Excellent Setup
- DCAPP Software
Description
Equipped with Newland’s 6th generation decoder chip, the MT37 Baiji can scan even damaged or poor quality barcodes with ease and speed.The special pre-installed DCAPP software allows customizing the MT37 Baiji to any solution you might require.
Light and Portable Data Collector
Made for high-demand operations, the MT37 Baiji provides a lightweight & ergonomic design to reduce fatigue during extended work sessions, and a long-lasting battery to get you through the entire shift without re-charging or switching out devices.
Superior Scanning Capabilities.
MT37 Baiji’s integrated 2D scan engine, equipped with Newland's 6th generation decoder chip, supports both 1D and 2D barcodes. The MT37 Baiji is set up to decode even damaged or poor-quality barcodes with ease and speed.
User-focused Ergonomics.
Made for high-demand operations, the MT37 Baiji renders a lightweight & ergonomic design to reduce fatigue during extended work sessions. The numeric keypad with some additional navigation buttons and a capacitive touch screen provides users with all the input choices they need.
Extended Battery Life.
The MT37 Baiji's 3300 mAh battery lasts up to 10 hours on a single charge. This enables you to get through your entire shift without re-charging or switching out devices.
Customized Android OS.
Built on Android 8.1 Go, the MT37 Baiji offers extended data security features, including Android's application protection and admin management tools.
Excellent Setup.
The MT37 Baiji is equipped with a Quad-Core processor, Android 8.1 Go OS, high-performance Dual-Band Wi-Fi, and Bluetooth 5.0 connection. Its rugged housing can withstand 1.2m drops to concrete.
DCAPP Software.
The MT37 Baiji comes with pre-installed and pre-licensed Newland DCAPP by Sysdev. Newland's DCAPP is a ready-to-use app that allows you to collect, transfer, and export data in a very simple way. With DCAPP, you can quickly start to collect data with 5 included pre-established templates of ready-to-be-used apps. It can then be synchronized with your PC or server to effortlessly export the gathered data.
Specifications
| Display | |
|---|---|
| Touch technology | Multi-touch |
| Touchscreen | Yes |
| Display resolution | 320 x 240 pixels |
| Display diagonal | 7.11 cm (2.8") |
| Memory | |
| Internal memory | 8 GB |
| Total storage capacity | 8 GB |
| RAM capacity | 1 GB |
| Flash memory | 8 GB |
| Processor | |
| Processor frequency | 1.8 GHz |
| Number of cores | 4 |
| Network | |
| Near Field Communication (NFC) | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Data network | 2G, 3G, 4G, LTE, WCDMA |
| Bluetooth version | 5.0 |
| Bluetooth | Yes |
| Wi-Fi | Yes |
| Bluetooth Low Energy (BLE) | Yes |
| GPS Performance | |
| GPS (satellite) | Yes |
| Audio | |
| Speakers | Yes |
| Ports & interfaces | |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| Performance | |
| RFID reader | Yes |
| Barcode reader | Yes |
| Drop proof | Yes |
| Drop proof | 120 cm |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, Dot Code A, MaxiCode, Micro QR Code, PDF417, QR Code |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), ISBN, ISSN, ITF-14, ITF-6, Industrial 2 of 5, MSI, Matrix 2 of 5, Plessey, UPC-A, UPC-E |
| Product colour | Black |
| Phone function | Yes |
| Vibrating alert | Yes |
| LED indicators | Yes |
| Keyboard layout | Alphanumeric |
| Scanner type | 1D/2D |
| Software | |
| Operating system version | 8.1 |
| Operating system installed | Android |
| Power | |
| Battery voltage | 3.8 V |
| Battery capacity | 3300 mAh |
| Weight & dimensions | |
| Width | 158 mm |
| Depth | 59 mm |
| Height | 18.3 mm |
| Weight | 155 g |
| Operational conditions | |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -20 - 50 °C |
| Packaging content | |
| Cables included | USB Type-C |
| Wireless LAN features | |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Wi-Fi | Yes |
| Data transmission | |
| Data network | 2G, 3G, 4G, LTE, WCDMA |
| Bluetooth version | 5.0 |
| Bluetooth | Yes |
| Bluetooth Low Energy (BLE) | Yes |
| Technical details | |
| RFID reader | Yes |
| Barcode reader | Yes |
| Drop proof | Yes |
| Drop proof | 120 cm |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, Dot Code A, MaxiCode, Micro QR Code, PDF417, QR Code |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), ISBN, ISSN, ITF-14, ITF-6, Industrial 2 of 5, MSI, Matrix 2 of 5, Plessey, UPC-A, UPC-E |
| Product colour | Black |
| Phone function | Yes |
| Vibrating alert | Yes |
| LED indicators | Yes |
| Keyboard layout | Alphanumeric |
| Cables included | USB Type-C |
| Scanner type | 1D/2D |
