Description
TOUGHBOOK 40, 14" IPS Touch LCD 1920x1080, Intel Core i5-1145G7, Intel Iris Xe Graphics, 16GB DDR4 RAM, 512GB NVMe OPAL SSD, Intel Wi-Fi6 AX201, Bluetooth 5.1, Thunderbolt 4, 4G, Windows 10 Pro
Class Leading 8 Modular Areas
The TOUGHBOOK 40 features eight user-replaceable locations including the battery, memory, storage, keyboard and four expansion areas. The expansion area features several different types of xPAK’s including a barcode reader, optical drives, authentication readers, additional I/O, batteries and storage. All of the options in the eight modular areas provide 6,048 combinations to choose from. This unparalleled customization enables organizations to help futureproof, simplify ordering, shorten lead times and decrease downtime.
Choice of 4G or 5G Modem
The 4G modem supports LTE, LTE-A and speeds up to 2 Gbps. The 5G modem supports 4G (LTE, LTE-A) as well as 5G (Sub6, C-band, mmWave) and speeds up to 5.5 Gbps. It seamlessly connects to the best available network without any disruption or intervention by the user. Both 4G and 5G modems support FirstNet® (band 14), CBRS Private LTE (band 48) and have dual SIM (physical SIM + eSIM) for maximum flexibility.
5MP Infrared Webcam
With the increased use of video conferencing – whether for telehealth or remote services – the TOUGHBOOK 40 boasts the first 5MP webcam in its class. It features a privacy cover for security and infrared capability to support Windows Hello facial recognition.
Tetra-array Microphones
Featuring four microphones that offer class leading speech recognition and up to 3x the accuracy in noisy environments. Additionally, users can select the optimal AI noise cancellation that best suits their needs.
Description
The 14” fully-rugged Panasonic TOUGHBOOK® 40 laptop breaks new ground offering unrivaled flexibility in even the most demanding and unpredictable environments with its class leading eight modular areas including its innovative modular expansion packs (xPAK’s). Optical drives, authentication readers, IO ports and even the Barcode Reader xPAK are all user upgradeable. Its state-of-the-art design optimizes thermals for maximum performance and its latest technology will ensure the TOUGHBOOK 40 will withstand the test of time. If features an optional dedicated GPU (late availability), up to 64GB of RAM, up to 3TB of storage, all-day battery life, four microphones, color-selectable backlit keyboard, 95db speakers, dual SIM (physical + eSIM) and choice of two cellular modems. The 4G modem provides up to 2Gbps and the 5G modem (late availability) adds support of 5G Sub6, C-band and mmWave with speeds up to 5.5Gbps and the ability to seamless connect to the best available network without any disruption or loss of connectivity.Class Leading 8 Modular Areas
The TOUGHBOOK 40 features eight user-replaceable locations including the battery, memory, storage, keyboard and four expansion areas. The expansion area features several different types of xPAK’s including a barcode reader, optical drives, authentication readers, additional I/O, batteries and storage. All of the options in the eight modular areas provide 6,048 combinations to choose from. This unparalleled customization enables organizations to help futureproof, simplify ordering, shorten lead times and decrease downtime.
Choice of 4G or 5G Modem
The 4G modem supports LTE, LTE-A and speeds up to 2 Gbps. The 5G modem supports 4G (LTE, LTE-A) as well as 5G (Sub6, C-band, mmWave) and speeds up to 5.5 Gbps. It seamlessly connects to the best available network without any disruption or intervention by the user. Both 4G and 5G modems support FirstNet® (band 14), CBRS Private LTE (band 48) and have dual SIM (physical SIM + eSIM) for maximum flexibility.
5MP Infrared Webcam
With the increased use of video conferencing – whether for telehealth or remote services – the TOUGHBOOK 40 boasts the first 5MP webcam in its class. It features a privacy cover for security and infrared capability to support Windows Hello facial recognition.
Tetra-array Microphones
Featuring four microphones that offer class leading speech recognition and up to 3x the accuracy in noisy environments. Additionally, users can select the optimal AI noise cancellation that best suits their needs.
Specifications
| Design | |
|---|---|
| Product type | Laptop |
| Form factor | Clamshell |
| Product colour | Black, Silver |
| Rugged design | Yes |
| Display | |
| HD type | Full HD |
| Panel type | IPS |
| Display brightness | 1200 cd/m² |
| Touchscreen | Yes |
| Touchscreen type | Capacitive |
| Display resolution | 1920 x 1080 pixels |
| Display diagonal | 35.6 cm (14") |
| Anti-glare screen | Yes |
| Processor | |
| Processor generation | 11th gen Intel® Core™ i5 |
| Configurable TDP-down | 12 W |
| Configurable TDP-down frequency | 1.1 GHz |
| Processor cache type | Smart Cache |
| Processor cache | 8 MB |
| Processor model | i5-1145G7 |
| Processor boost frequency | 4.4 GHz |
| Processor cores | 4 |
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i5 |
| Configurable TDP-up frequency | 2.6 GHz |
| Configurable TDP-up | 28 W |
| Memory | |
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 3200 MHz |
| Memory slots | 2x SO-DIMM |
| Maximum internal memory | 64 GB |
| Storage | |
| SSD form factor | M.2 |
| Storage media | SSD |
| Number of SSDs installed | 1 |
| SSD capacity | 512 GB |
| SSD interface | NVMe |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSDXC |
| Total storage capacity | 512 GB |
| NVMe | Yes |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card | Yes |
| On-board graphics card model | Intel Iris Xe Graphics |
| Discrete graphics card model | Not available |
| On-board GPU manufacturer | Intel |
| Audio | |
| Built-in microphone | Yes |
| Camera | |
| Front camera | Yes |
| Front camera resolution (numeric) | 5 MP |
| Privacy camera | Yes |
| Privacy type | Privacy cover |
| Windows Hello | Yes |
| Network | |
| Mobile network connection | Yes |
| Mobile network generation | 4G |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| WLAN controller model | Intel Wi-Fi 6 AX201 |
| 4G standard | LTE |
| Wi-Fi standards | Wi-Fi 6 (802.11ax) |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Bluetooth | Yes |
| Bluetooth version | 5.1 |
| WLAN controller manufacturer | Intel |
| Ports & interfaces | |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Combo headphone/mic port | Yes |
| Thunderbolt 4 ports quantity | 1 |
| Intel® Thunderbolt 4 | Yes |
| Keyboard | |
| Pointing device | Touchpad |
| Numeric keypad | No |
| Software | |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 10 Pro |
| Technical details | |
| Form factor | Clamshell |
| Product colour | Black, Silver |
| Processor special features | |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel Software Guard Extensions (Intel SGX) | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Idle States | Yes |
| CPU configuration (max) | 1 |
| Intel Virtualization Technology (VT-x) | Yes |
| Battery | |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery life (max) | 18 h |
| Battery capacity | 6500 mAh |
| Battery recharge time | 3 h |
| Power | |
| AC adapter frequency | 50/60 Hz |
| AC adapter input voltage | 100 - 240 V |
| Security | |
| Password protection | Yes |
| Cable lock slot type | Kensington |
| Trusted Platform Module (TPM) | Yes |
| Cable lock slot | Yes |
| Windows Hello | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -29 - 63 °C |
| Drop proof | 180 cm |
| Weight & dimensions | |
| Width | 354 mm |
| Depth | 54.4 mm |
| Height | 301 mm |
| Weight | 3.35 kg |
| Other features | |
| WLAN controller model | Intel Wi-Fi 6 AX201 |
| On-board graphics card | Yes |
| Anti-glare screen | Yes |
