Description
M3088-V, CMOS, 1/2.8", WDR, 3840 x 2160, IK08, IP42
Key Features
- Built-in cybersecurity features; Compact, discreet design; Great image quality in 8 MP; Support for analytics with deep learning; WDR for challenging light
Description
This cost-efficient mini dome features Wide Dynamic Range (WDR) to ensure clarity even when there’s both dark and light areas in the scene. A deep learning processing unit enables intelligent analytics based on deep learning on the edge. Plus, AXIS Object Analytics including time in area feature lets you track whenever an object stays in a defined area longer than a user-defined time, for example, to detect loitering. This compact, easy-to-install, vandal-resistant camera comes factory focused so there’s no manual focusing required. Furthermore, Axis Edge Vault protects your Axis device ID and simplifies authorization of Axis devices on your network.Specifications
| Performance | |
|---|---|
| Infrared (IR) cut-off filter | Yes |
| Number of languages | 18 |
| Languages support | Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| PTZ modes | Digital PTZ |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Indoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Design | |
| IK code | IK08 |
| Form factor | Dome |
| Product colour | White |
| Mounting type | Ceiling/wall |
| Protection features | Dust resistant, Impact resistant, Water resistant |
| International Protection (IP) code | IP42 |
| Housing material | Acrylonitrile butadiene styrene (ABS), Polycarbonate (PC) |
| Camera | |
| Minimum illumination | 0.25 lx |
| Tilt angle range | 0 - 80° |
| Pan range | 0 - 175° |
| Angle of rotation | 175° |
| Camera shutter speed | 1/71500 - 1/5 s |
| Lens viewing angle, horizontal | 109° |
| Lens viewing angle, vertical | 56° |
| Progressive scan | Yes |
| Image sensor | |
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Number of sensors | 1 |
| Lens system | |
| Focal length range | 2.9 mm |
| Night vision | |
| Night vision | Yes |
| Video | |
| Image quality adjustment | Brightness, Contrast, Sharpness |
| Privacy masking | Yes |
| Video compression formats | H.264, H.265, M-JPEG, MPEG4 |
| Maximum resolution | 3840 x 2160 pixels |
| Frame rate | 15 fps |
| Total megapixels | 8 MP |
| Audio | |
| Audio system | 2-way |
| Network | |
| Bluetooth | No |
| Networking standards | IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Quality of Service (QoS) support | Yes |
| Number of users | 1 user(s) |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSb , HTTP/2, TLSb , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTCP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Storage | |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Internal memory | 2048 MB |
| Flash memory | 512 MB |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security | |
| Video motion detection | Yes |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Password protection | Yes |
| Pixel counter | Yes |
| Digest authentication | Yes |
| Network access storage (NAS) | Yes |
| Power | |
| Power source type | PoE |
| Power consumption (max) | 4.2 W |
| Power consumption (typical) | 3.6 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Height | 56 mm |
| Diameter | 10.1 cm |
| Weight | 150 g |
| Packaging content | |
| Number of cameras | 1 |
| Manual | Yes |
| Technical details | |
| Doesn't contain | BFR, PVC |
| Warranty period | 5 year(s) |
| Other features | |
| Video compression formats | H.264, H.265, M-JPEG, MPEG4 |
