Description
8 x 10/100/1000 ethernet ports, 2 x SFP+ ports, SwitchOS Lite, White
There are two SFP+ ports for 10 Gigabit fiber connectivity and eight Gigabit Ethernet ports with 802.3af/at PoE-out.
This switch is all about nice and easy setups. The compact form-factor means easier shipping and handling, while the lightweight SwOS means easier configuration. You can even configure this switch from your web browser! It gives you all the core functionality of a managed switch, and even more: you can manage port-to-port forwarding, broadcast storm control, apply MAC filters, configure VLANs, mirror traffic, apply bandwidth limitations, and even adjust some MAC and IP header fields.
But the real blessing is the combination of SFP+ and PoE-out Ethernet ports. With this setup, you can do all kinds of things on a tight budget. CSS610 has an impressive total PoE-out budget of 140 W, so you can use even in the most intense scenarios – like hotels, conference halls, or call centers! Use the PoE-out ports to connect the IP-phones while the SFP+ ports connect your primary server to the ISP. Or power a bunch of network cameras and instantly upload the footage to the cloud. And manage a cluster of wireless access points at the same time. Also, scalability is no longer a problem. With our pricing, you can afford a switch on every floor!
Like every toolbox needs screwdrivers and pliers, every network can use a solid PoE switch.
Description
CSS610-8P-2S+IN is one of the most well-rounded switches on the market. It is a perfect fit for the most diverse setups: from home networks and small offices to hotels, call centers and so on. The unique combination of size, features, and price offers unbelievable scalability potential.There are two SFP+ ports for 10 Gigabit fiber connectivity and eight Gigabit Ethernet ports with 802.3af/at PoE-out.
This switch is all about nice and easy setups. The compact form-factor means easier shipping and handling, while the lightweight SwOS means easier configuration. You can even configure this switch from your web browser! It gives you all the core functionality of a managed switch, and even more: you can manage port-to-port forwarding, broadcast storm control, apply MAC filters, configure VLANs, mirror traffic, apply bandwidth limitations, and even adjust some MAC and IP header fields.
But the real blessing is the combination of SFP+ and PoE-out Ethernet ports. With this setup, you can do all kinds of things on a tight budget. CSS610 has an impressive total PoE-out budget of 140 W, so you can use even in the most intense scenarios – like hotels, conference halls, or call centers! Use the PoE-out ports to connect the IP-phones while the SFP+ ports connect your primary server to the ISP. Or power a bunch of network cameras and instantly upload the footage to the cloud. And manage a cluster of wireless access points at the same time. Also, scalability is no longer a problem. With our pricing, you can afford a switch on every floor!
Like every toolbox needs screwdrivers and pliers, every network can use a solid PoE switch.
Specifications
| Management features | |
|---|---|
| Reset button | Yes |
| Switch type | Managed |
| Virtual LAN features | |
| VLAN support | Yes |
| Technical details | |
| Product colour | White |
| Mean time between failures (MTBF) | 200000 h |
| Rack mounting | Yes |
| Sustainability compliance | Yes |
| Compliance certificates | CE, RoHS |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP+ modules quantity | 2 |
| Network | |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| VLAN support | Yes |
| Broadcast storm control | Yes |
| 10G support | Yes |
| Data transmission | |
| Switching capacity | 56 Gbit/s |
| Security | |
| MAC address filtering | Yes |
| Certificates | |
| Certification | EAC |
| Memory | |
| Flash memory | 0.064 MB |
| Design | |
| International Protection (IP) code | IP20 |
| Reset button | Yes |
| Product colour | White |
| LED indicators | Yes |
| Certification | EAC |
| Rack mounting | Yes |
| Performance | |
| Mean time between failures (MTBF) | 200000 h |
| Flash memory | 0.064 MB |
| Processor model | Marvell 88E6193X |
| Fanless | Yes |
| Operating system installed | SwitchOS Lite |
| Indication | |
| LED indicators | Yes |
| Power | |
| Power consumption (max) | 162 W |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 2.2 A |
| DC input voltage | 48 - 57 V |
| Power source | AC/DC |
| Power over Ethernet (PoE) | |
| Total Power over Ethernet (PoE) budget | 140 W |
| Power over Ethernet (PoE) ports quantity | 8 |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | Passive PoE |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Weight & dimensions | |
| Width | 272 mm |
| Depth | 216 mm |
| Height | 50 mm |
| Packaging data | |
| Rack mount kit | Yes |
| Cables included | AC |
| Sustainability | |
| Sustainability compliance | Yes |
| Packaging content | |
| Rack mount kit | Yes |
| Cables included | AC |
