Acer Basic X1629HK, 4500 ANSI lumens, DLP, WUXGA (1920x1200), 10000:1, 16:10, 685.8 - 7620 mm (27 - 300")
Description
Acer Basic X1629HK. Projector brightness: 4500 ANSI lumens, Projection technology: DLP, Projector native resolution: WUXGA (1920x1200). Light source type: Lamp, Lamp type: OSRAM, Lamp power: 245 W. Focal length range: 15.85 - 17.44 mm, Digital zoom: 2x, Optical zoom: 1.1x. Analog signal format system: NTSC, PAL, SECAM, Supported graphics resolutions: 1920 x 1200 (WUXGA), Supported video modes: 1080p. Serial interface type: RS-232, HDMI connector type: Full-size
Specifications
| Projector |
|---|
| Number of colours |
1.07 billion colours |
| Projector native resolution |
WUXGA (1920x1200) |
| Native aspect ratio |
16:10 |
| Supported aspect ratios |
4:3, 16:10, 16:9 |
| Screen size compatibility |
685.8 - 7620 mm (27 - 300") |
| Projection distance |
1 - 9.7 m |
| Contrast ratio (typical) |
10000:1 |
| Zoom capability |
Yes |
| Vertical synchronization (min) |
0.024 kHz |
| Vertical synchronization (max) |
0.12 kHz |
| Keystone correction, vertical |
-40 - 40° |
| Horizontal synchronization (min) |
15 kHz |
| Horizontal synchronization (max) |
100 kHz |
| Projection technology |
DLP |
| Projector brightness |
4500 ANSI lumens |
| Projection modes |
Ceiling, Front, Rear |
| Lamps |
|---|
| Lamp type |
OSRAM |
| Lamps quantity |
1 lamp(s) |
| Lamp power |
245 W |
| Light source type |
Lamp |
| Light source |
|---|
| Lamp type |
OSRAM |
| Lamps quantity |
1 lamp(s) |
| Lamp power |
245 W |
| Light source type |
Lamp |
| Lens system |
|---|
| Zoom capability |
Yes |
| Focal length range |
15.85 - 17.44 mm |
| Optical zoom |
1.1x |
| Digital zoom |
2x |
| Video |
|---|
| Analog signal format system |
NTSC, PAL, SECAM |
| 3D |
Yes |
| Supported video modes |
1080p |
| Supported graphics resolutions |
1920 x 1200 (WUXGA) |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
1 |
| RMS rated power |
3 W |
| Ports & interfaces |
|---|
| HDMI connector type |
Full-size |
| HDMI ports quantity |
2 |
| USB 2.0 ports quantity |
1 |
| Audio (L/R) in |
1 |
| Audio (L/R) out |
1 |
| Serial interface type |
RS-232 |
| DVI port |
No |
| AC (power) in |
Yes |
| Network |
|---|
| Smart TV |
No |
| Ethernet LAN |
No |
| Storage |
|---|
| Card reader integrated |
No |
| Technical details |
|---|
| Product colour |
White |
| Projection modes |
Ceiling, Front, Rear |
| Lamp power |
245 W |
| Performance |
|---|
| Market positioning |
Presentation |
| Built-in processor |
No |
| Features |
|---|
| Interactive |
No |
| Projection modes |
Ceiling, Front, Rear |
| Compatible operating systems |
Google Chrome PC, Mac PC, Windows PC |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
1 |
| RMS rated power |
3 W |
| Built-in microphone |
No |
| Design |
|---|
| Market positioning |
Presentation |
| Product colour |
White |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| AC input voltage |
120 - 230 V |
| Power source |
AC |
| Power consumption (typical) |
290 W |
| Power consumption (standby) |
0.5 W |
| Processor |
|---|
| Built-in processor |
No |
| Weight & dimensions |
|---|
| Weight |
2.6 kg |
| Width |
322 mm |
| Depth |
225 mm |
| Height |
91 mm |
