Description
1/2.8" CMOS, 2 MP, 1080p, 4.3-129mm, PTZ, RS-232, HDMI, RJ-45, 201x210x176 mm
The PTC500S integrates auto tracking, Multi-Presenter Detection, and streaming with a superior dual lens tracking design.
Boasting a PTZ camera with a powerful 30X optical zoom and a secondary 120° FOV panoramic camera, the PTC500S stably captures full HD 1080p video without the need for a camera operator.
Up to 30X Optical Zoom
Featuring a PTZ camera with market-leading 30X optical zoom, the PTC500S sports a 350° pan and 120° tilt radius that are perfectly suited for large classrooms or auditoriums. Full HD 1080p 60fps video and a powerful remote autofocus function track the moving presenter more precisely and display important details more distinctly. Capture the full joy of the classroom with the most realistic and dynamic image quality.
No Extra Devices Needed
Exclusive algorithms enable the PTC500S to automatically track a presenter’s face and movements. Speakers are free to walk around the classroom without wearing any accessories to give guidance and solve problems for students, ensuring quality education. With no need to worry about the connection restrictions, charging security, or added expense of a wearable device, you can focus on building zero-distance interactive teaching.
Dual Lens Design
A dual lens design integrates a PTZ camera with a super-wide 120° FOV secondary camera to track the speaker and capture a panoramic view of the classroom at the same time. Also, enable and adjust PIP mode while capturing to simultaneously view the speaker and the rest of the room. Clearly present every detail of the lesson and never miss a teachable moment.
Multi-Presenter Detection
Industry leading Multi-Presenter Detection accurately tracks when there are two or more people in the effective area. This feature allows teachers to conduct group discussions, quiz contests, interactive games, and more. Use one camera to capture every detail of every learning situation.
Capture Every Interaction
Track your target everywhere with Wide Area Tracking. This feature provides presenters the flexibility to leave the stage and interact with a crowd or students, all while being continuously tracked even if obscured by other people or objects.
Description
Professional Auto Tracking CameraThe PTC500S integrates auto tracking, Multi-Presenter Detection, and streaming with a superior dual lens tracking design.
Boasting a PTZ camera with a powerful 30X optical zoom and a secondary 120° FOV panoramic camera, the PTC500S stably captures full HD 1080p video without the need for a camera operator.
Up to 30X Optical Zoom
Featuring a PTZ camera with market-leading 30X optical zoom, the PTC500S sports a 350° pan and 120° tilt radius that are perfectly suited for large classrooms or auditoriums. Full HD 1080p 60fps video and a powerful remote autofocus function track the moving presenter more precisely and display important details more distinctly. Capture the full joy of the classroom with the most realistic and dynamic image quality.
No Extra Devices Needed
Exclusive algorithms enable the PTC500S to automatically track a presenter’s face and movements. Speakers are free to walk around the classroom without wearing any accessories to give guidance and solve problems for students, ensuring quality education. With no need to worry about the connection restrictions, charging security, or added expense of a wearable device, you can focus on building zero-distance interactive teaching.
Dual Lens Design
A dual lens design integrates a PTZ camera with a super-wide 120° FOV secondary camera to track the speaker and capture a panoramic view of the classroom at the same time. Also, enable and adjust PIP mode while capturing to simultaneously view the speaker and the rest of the room. Clearly present every detail of the lesson and never miss a teachable moment.
Multi-Presenter Detection
Industry leading Multi-Presenter Detection accurately tracks when there are two or more people in the effective area. This feature allows teachers to conduct group discussions, quiz contests, interactive games, and more. Use one camera to capture every detail of every learning situation.
Capture Every Interaction
Track your target everywhere with Wide Area Tracking. This feature provides presenters the flexibility to leave the stage and interact with a crowd or students, all while being continuously tracked even if obscured by other people or objects.
Specifications
| Camera | |
|---|---|
| Megapixel (approx.) | 2 MP |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Optical zoom | 30x |
| Digital zoom | 12x |
| Focal length range | 4.3 - 129 mm |
| Field of view (FOV) angle | 76° |
| Minimum illumination | 0.23 lx |
| White balance | Auto, Manual |
| Signal-to-Noise Ratio (SNR) | 50 dB |
| Noise reduction | Yes |
| Back Light Compensation (BLC) | Yes |
| Gain control type | Auto/Manual |
| Minimum working distance (wide) | 0.1 mm |
| Maximum working distance (tele) | 1.2 mm |
| Aperture range (F-F) | 1.6 - 4.7 |
| Auto exposure | Yes |
| Number of camera presets | 10 |
| Slowest camera shutter speed | 0.2 s |
| Network streaming | Yes |
| Fastest camera shutter speed | 1/32000 s |
| Video | |
| Maximum video resolution | 1920 x 1080 pixels |
| Maximum frame rate | 60 fps |
| Resolution at capture speed | 1280x720@60fps, 1920x1080@30fps, 1920x1080@50fps, 1920x1080@60fps |
| Supported video modes | 720p, 1080i, 1080p |
| Video formats supported | H.264 |
| HD type | Full HD |
| Baud rate | 115.2 Kbit/s |
| Design | |
| Product colour | Black |
| Tilt angle range | -30 - 90° |
| Pan range | -175 - 175° |
| LED indicators | Power |
| Country of origin | Taiwan |
| Tilt speed (min) | 2 °/sec |
| Tilt speed (max) | 50 °/sec |
| Pan speed (min) | 2 °/sec |
| Pan speed (max) | 50 °/sec |
| Ports & interfaces | |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| 3G-SDI output | Yes |
| Power | |
| DC input voltage | 12 V |
| Power source type | DC |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 20 - 95% |
| Technical details | |
| Harmonized System (HS) code | 8525890000 |
| Audio | |
| Noise reduction | Yes |
| Protocols | |
| Supported network protocols | RTSP, RTMP, ONVIF |
| Network | |
| Supported network protocols | RTSP, RTMP, ONVIF |
| Network streaming | Yes |
| Packaging content | |
| Quick start guide | Yes |
| Remote control included | Yes |
| Power supply included | Yes |
| Performance | |
| Remote control function | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Logistics data | |
| Products per pallet | 48 pc(s) |
| Products per master (outer) case | 2 pc(s) |
| Harmonized System (HS) code | 8525890000 |
| Weight & dimensions | |
| Width | 296 mm |
| Depth | 250 mm |
| Height | 256 mm |
| Weight | 7.17 kg |
| Packaging data | |
| Package width | 312 mm |
| Package depth | 286 mm |
| Package height | 520 mm |
| Package weight | 8 kg |
