Description
5G, 802.11b/g/n/ac, Gigabit Ethernet, Quad-core ARM Cortex A7 717 MHz, 256MB RAM, USB, RutOS, 533 g
RUTX50 is a dual-SIM multi-network router offering 5G mobile communication for high-speed and data-heavy applications. Together with 5x Gigabit Ethernet ports and dual-band Wi-Fi, it provides data connection redundancy with auto-failover. Backward compatibility and multiple interfaces allow for long-term expandability and upgrading options.
Key Features
- RUTX50 is your future-proof, multi-network industrial router, offering 5G mobile communication for high-speed and data-heavy applications
- 5G dual SIM cellular communication combined with 5 Gigabit Ethernet ports and dual-band Wi-Fi enables reliable ultra-low latency data transfer
- The power of 5G technology, combined with a wide range of interfaces and industrial hardware features, ensures adaptability for future upgrades and expansions
- RUTX50 comes with the RutOS, which provides advanced security features and specialized industrial protocols for a wide range of professional application scenarios, and is compatible with our Remote Management System (RMS), for optimized remote management and monitoring capabilities of large fleets of devices
Description
INDUSTRIAL 5G ROUTERRUTX50 is a dual-SIM multi-network router offering 5G mobile communication for high-speed and data-heavy applications. Together with 5x Gigabit Ethernet ports and dual-band Wi-Fi, it provides data connection redundancy with auto-failover. Backward compatibility and multiple interfaces allow for long-term expandability and upgrading options.
Specifications
| Technical details | |
|---|---|
| Device type | Cellular network router |
| Data network | 3G, 4G, 5G |
| Ethernet LAN features | |
| Ethernet LAN (RJ-45) ports | 4 |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Auto MDI/MDI-X | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.3, IEEE 802.3az, IEEE 802.3u |
| Cellular interface | |
| 4G standard | LTE |
| Design | |
| Housing material | Aluminium |
| Device type | Cellular network router |
| Product colour | Stainless steel |
| Reset button | Yes |
| LED indicators | LAN, Power, WAN, WLAN |
| Wireless LAN features | |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Mobile network | |
| Data network | 3G, 4G, 5G |
| 4G standard | LTE |
| SIM card type | MiniSIM |
| 5G standard | Sub6 SA/NSA |
| Ports & interfaces | |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 4 |
| USB port | Yes |
| Security | |
| Port forwarding | Yes |
| Security algorithms | WPA3-EAP, WPA2-Enterprise-PEAP, AES-CCMP, TKIP, WEP, WPA2-PSK, WPA3-SAE |
| Network address translation (NAT) | Yes |
| Firewall | Yes |
| Packaging content | |
| Cables included | LAN (RJ-45) |
| Material | |
| Housing material | Aluminium |
| Performance | |
| Operating system installed | RutOS |
| Built-in processor | Yes |
| Processor frequency | 0.717 GHz |
| RAM capacity | 0.256 GB |
| Management features | |
| Web-based management | Yes |
| Antenna | |
| Antenna connector type | SMA |
| Antennas quantity | 7 |
| Detachable antenna(s) | Yes |
| Power | |
| Input voltage | 9 - 50 V |
| Power source type | DC |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Weight | 533 g |
| Width | 132 mm |
| Depth | 95.1 mm |
| Height | 44.2 mm |
| Packaging data | |
| Cables included | LAN (RJ-45) |
