Description
Catalyst 2960CX-8PC-L Network Switch, 8 Gigabit Ethernet Ports, 8 PoE+ Outputs, 124W PoE Budget, two 1 G SFP and two 1 G Copper Uplinks, Enhanced Limited Lifetime Warranty (WS-C2960CX-8PC-L)
Description
The Cisco Catalyst 2960CX-8PC-L Network Switch is ideal for high-speed data connectivity, Wi-Fi backhaul and PoE+ connectivity in places where space is at a premium. Featuring a compact design and quiet, fanless operation, this managed switch can come out of the server room and be placed closer to users, meaning shorter cable runs and greater flexibility for your network deployment.Specifications
| Management features | |
|---|---|
| Switch type | Managed |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Switch layer | L2/L3 |
| Ports & interfaces | |
| SFP+ module slots quantity | 2 |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 2 |
| Console port | RJ-45 |
| Power connector | DC-in jack |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-T, 10GBASE-T |
| Network | |
| Copper ethernet cabling technology | 1000BASE-T, 100BASE-T, 10GBASE-T |
| Networking standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3z |
| Full duplex | Yes |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Rate limiting | Yes |
| Number of VLANs | 4000 |
| Link aggregation | Yes |
| 10G support | No |
| IGMP snooping | Yes |
| Data transmission | |
| Jumbo frames | 9198 |
| Switching capacity | 24 Gbit/s |
| Jumbo frames support | Yes |
| Forwarding rate | 17.9 Mpps |
| Number of VLANs | 4000 |
| Security | |
| IGMP snooping | Yes |
| DHCP features | DHCP server |
| Multicast features | |
| Multicast support | Yes |
| Protocols | |
| Management protocols | Telnet, RIP, SNMP, NTP, TACACS+, RMON, HTTP, RADIUS |
| Supported network protocols | ICMP, ARP, BOOTP, OSPF, DHCP |
| Design | |
| Product colour | White |
| LED indicators | Yes |
| Rack mounting | No |
| Market segment | Business |
| Country of origin | China |
| Certification | FCC, CE, CFR 47, EN 55022, EN 55024, AS/NZS, CISPR22:2004, EN55022, VCCI, KCC, ANATEL, CCC, GOST |
| Performance | |
| Mean time between failures (MTBF) | 569530 h |
| Internal memory | 512 MB |
| Flash memory | 128 MB |
| Harmonized System (HS) code | 85176990 |
| Power | |
| Power plug type | Type C |
| AC input voltage | 100 - 240 V |
| Power consumption (typical) | 24.5 W |
| Input current | 1.5 - 3.25 A |
| Power connector | DC-in jack |
| Power over Ethernet (PoE) | |
| Power over Ethernet plus (PoE+) ports quantity | 8 |
| Total Power over Ethernet (PoE) budget | 124 W |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
| Storage temperature (T-T) | -25 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -5 - 45 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 4000 m |
| Heat dissipation | 648.3 BTU/h |
| Virtual LAN features | |
| VLAN support | Yes |
| Number of VLANs | 4000 |
| Weight & dimensions | |
| Width | 269 mm |
| Depth | 238 mm |
| Height | 44.4 mm |
| Weight | 2.27 kg |
| Packaging data | |
| Package width | 327.7 mm |
| Package depth | 349.2 mm |
| Package height | 160.3 mm |
| Package weight | 2.27 kg |
| Technical details | |
| Product colour | White |
| Mean time between failures (MTBF) | 569530 h |
| Rack mounting | No |
| Memory | |
| Internal memory | 512 MB |
| Flash memory | 128 MB |
| Certificates | |
| Certification | FCC, CE, CFR 47, EN 55022, EN 55024, AS/NZS, CISPR22:2004, EN55022, VCCI, KCC, ANATEL, CCC, GOST |
| Indication | |
| LED indicators | Yes |
| Other features | |
| Country of origin | China |
| Logistics data | |
| Country of origin | China |
| Harmonized System (HS) code | 85176990 |
| Quantity per pack | 1 pc(s) |
