Description
5G, Single core ARM Cortex A7 1.5 GHz, 256MB RAM, RutOS, Gigabit Ethernet
TRB500 is a compact, energy-efficient 5G gateway for ultra-fast data transmission with ultra-low latency. Backward compatibility with 4G and 3G networks enables future-proofing solution infrastructures even in areas where 5G is not yet available.
Key Features
- The TRB500 gateway is a compact-sized and energy-efficient industrial gateway with a Gigabit Ethernet interface and two configurable I/Os, allowing high-level customization and implementation of a multitude of scenarios
- This device enables 5G network speeds with ultra-low latency for mission-critical infrastructures and high data throughput, ensured by 4 external antennas that allow the use of 4x4 MIMO
- TRB500 comes with the RutOS operating system, which provides advanced security features and compatibility with our Remote Management System (RMS) for optimized remote management and monitoring capabilities of large fleets of devices
Description
INDUSTRIAL 5G GATEWAYTRB500 is a compact, energy-efficient 5G gateway for ultra-fast data transmission with ultra-low latency. Backward compatibility with 4G and 3G networks enables future-proofing solution infrastructures even in areas where 5G is not yet available.
Specifications
| Design | |
|---|---|
| LED indicators | LAN, Power, Signal strength, Status |
| Mounting type | DIN-rail/Wall mounting |
| Product colour | Stainless steel |
| International Protection (IP) code | IP30 |
| Enclosure material | Aluminum |
| Features | |
| Antenna type | External |
| Short Message Service (SMS) | Yes |
| Antenna connector type | SMA |
| Antennas quantity | 4 |
| Built-in processor | Yes |
| Processor frequency | 1500 MHz |
| Performance | |
| Built-in processor | Yes |
| Processor frequency | 1500 MHz |
| Internal memory | 256 MB |
| Flash memory | 512 MB |
| Control display unit | No |
| Mounting type | DIN-rail/Wall mounting |
| Product colour | Stainless steel |
| International Protection (IP) code | IP30 |
| Enclosure material | Aluminum |
| Protocols | |
| Supported network protocols | TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, SMTP, SSL v3, TLS, PPP, PPPoE, SSH, DHCP, SNMP, MQTT, Wake on LAN (WOL) |
| Routing protocols | NHRP, BGP, EIGRP, OSPFv2, RIP-1, RIP-2 |
| Network | |
| Dynamic DNS (DDNS) | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Security | |
| VLAN support | Yes |
| DoS attack prevention | Yes |
| MAC address filtering | Yes |
| Firewall security | Yes |
| Network address translation (NAT) | Yes |
| Ports & interfaces | |
| Number of simultaneous SIM cards | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| SIM card type | MiniSIM |
| SIM card slot | Yes |
| Management features | |
| Web-based management | Yes |
| Syslog | Yes |
| Reset button | Yes |
| Power | |
| DC input voltage | 9 - 30 V |
| Power consumption (max) | 6 W |
| Weight & dimensions | |
| Weight | 241 g |
| Width | 100 mm |
| Height | 30 mm |
| Depth | 93.4 mm |
| Packaging content | |
| Cables included | LAN (RJ-45), Micro-USB |
| Quick start guide | Yes |
| AC adapter included | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Technical details | |
| Built-in processor | Yes |
| Antenna type | External |
| Short Message Service (SMS) | Yes |
| Quick start guide | Yes |
| Processor frequency | 1500 MHz |
| Number of simultaneous SIM cards | 1 |
| Antenna connector type | SMA |
| AC adapter included | Yes |
| Indication | |
| LED indicators | LAN, Power, Signal strength, Status |
| Memory | |
| Internal memory | 256 MB |
| Flash memory | 512 MB |
| Display | |
| Control display unit | No |
| Antenna | |
| Antenna type | External |
| Antenna connector type | SMA |
| Antennas quantity | 4 |
