Description
1/2.8" CMOS, 2592x1944px, 5MP, 30 fps, 12V PoE
Make faster, informed decisions with a camera that differentiates normal activity from suspicious behavior and tells you when to intervene.
Real-time threat detection
Reduce false alarm fatigue and enable faster responses with Smart Analytics.
Pelco Elevate
Expand beyond the edge with Elevate, our direct camera-to-cloud technology that pairs with your existing VMS.
Seamless integration
Built on an open system for straightforward installation and configuration.
Description
Impeccable imaging for advanced insightsMake faster, informed decisions with a camera that differentiates normal activity from suspicious behavior and tells you when to intervene.
Real-time threat detection
Reduce false alarm fatigue and enable faster responses with Smart Analytics.
Pelco Elevate
Expand beyond the edge with Elevate, our direct camera-to-cloud technology that pairs with your existing VMS.
Seamless integration
Built on an open system for straightforward installation and configuration.
Specifications
| Performance | |
|---|---|
| Infrared (IR) cut-off filter | Yes |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Certification | UL/CSA/EN/IEC 62368-1, IEC 62471, FCC Part 15 Subpart B (Class B), IC ICES-003 (Class B), EN 55032 (Class B), EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 50130-4, EN 50121-4 |
| Dynamic range | 130 dB |
| Design | |
| Weatherproof | Yes |
| IK code | IK10 |
| Form factor | Dome |
| Product colour | Black, White |
| Mounting type | Ceiling |
| International Protection (IP) code | IP66, IP67 |
| Housing material | Plastic, Polycarbonate (PC) |
| Camera | |
| Minimum illumination | 0.02 lx |
| Tilt angle range | 8 - 95° |
| Pan range | 0 - 360° |
| White balance | Auto, Manual |
| Angle of rotation | 360° |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/7.5 - 1/30000 s |
| Lens viewing angle, horizontal | 95° |
| Lens viewing angle, vertical | 69° |
| Number of Privacy masking areas | 64 |
| Image sensor | |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Number of sensors | 1 |
| Lens system | |
| Number of lenses | 1 |
| Maximum aperture number | 1.6 |
| Auto focus | Yes |
| Focus | Motorized |
| Zoom capability | Yes |
| Focal length range | 3.4 - 10.5 mm |
| Video | |
| Noise reduction | Yes |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Maximum resolution | 2592 x 1944 pixels |
| Video formats supported | H.264, H.265, M-JPEG |
| Supported graphics resolutions | 384 x 288, 512 x 288, 512 x 384, 640 x 360, 640 x 480 (VGA), 768 x 432, 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1440 x 1080, 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2560 x 1440, 2592 x 1944 |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Total megapixels | 5 MP |
| Video intelligence analytic | Yes |
| Audio | |
| Sample rate | 8 kHz |
| Signal-to-Noise Ratio (SNR) | 50 dB |
| Audio formats supported | G.711, PCM |
| Network | |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.3af |
| Streaming method | Multicast |
| Ethernet LAN | Yes |
| Supported network protocols | IPv6, IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMPv3, ICMP, DHCP, Zeroconf, HSTS, RTP/UDP, RTP/UDP multicast, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/RTSP/HTTPS/TCP, HTTP, SRTP, SNMP v2c, SNMP v3 |
| Storage | |
| Maximum memory card size | 1.5 TB |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 512 MB |
| RAM capacity | 1000 MB |
| Ports & interfaces | |
| USB port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security | |
| Privacy protection | Yes |
| Intelligent Video Surveillance (IVS) system features | Line crossing detection, Missing object, Moving object, Region entrance detection, Region exiting detection |
| Video motion detection | Yes |
| HTTPS encryption | Yes |
| Password protection | Yes |
| Digest authentication | Yes |
| Power | |
| Power source type | Battery, PoE |
| Power consumption (Power over Ethernet (PoE)) | 8 W |
| Battery technology | Lithium |
| Battery | |
| Battery technology | Lithium |
| Certificates | |
| Certification | UL/CSA/EN/IEC 62368-1, IEC 62471, FCC Part 15 Subpart B (Class B), IC ICES-003 (Class B), EN 55032 (Class B), EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 50130-4, EN 50121-4 |
| Operational conditions | |
| Operating temperature (T-T) | -14 - 60 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions | |
| Width | 156 mm |
| Depth | 156 mm |
| Height | 116 mm |
| Weight | 810 g |
| Sustainability | |
| Compliance certificates | BIS, CE, KC, Norma Oficial Mexicana (NOM), RCM, RoHS, UKCA, UL, cUL |
| Packaging content | |
| Number of cameras | 1 |
| Technical details | |
| Compliance certificates | BIS, CE, KC, Norma Oficial Mexicana (NOM), RCM, RoHS, UKCA, UL, cUL |
| Other features | |
| Focus | Motorized |
