CMOS 1/1.2, Lightfinder 2.0, 0.07 lux, 3840 x 2160, IK10+, IP66, IP6K9K
Key Features
- Built-in cybersecurity features; Ideal for corrosive and harsh conditions; Marine-grade stainless steel casing; Outstanding image quality in 4K; Support for analytics with deep learning
Description
Enclosed in marine-grade stainless steel (SS 316L), DNV-certified casing, this robust camera is resistant to the corrosive effects of sea water and cleaning chemicals. Plus, it’s protected against redirection, defocusing, and impacts and can withstand wide temperatures ranges. It offers outstanding image quality in superior 4K resolution under any light conditions. Featuring a deep learning processing unit (DLPU), it supports advanced analytics based on deep learning on the edge. And, thanks to AXIS Object Analytics, it can detect and classify people, and different types of vehicles—all tailored to specific needs. Furthermore, built-in cybersecurity features help safeguard your system.
Specifications
| Performance |
|---|
| Infrared (IR) cut-off filter |
Yes |
| Number of languages |
12 |
| Languages support |
Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian |
| PTZ modes |
Digital PTZ |
| Type |
IP security camera |
| Connectivity technology |
Wired |
| PTZ control |
Yes |
| Placement supported |
Indoor & outdoor |
| Wide Dynamic Range (WDR) |
Yes |
| Day/night mode |
Yes |
| Certification |
CISPR 35, EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), IEC 62236-4, KS C 9832 Class A, KS C 9835, RCM AS/NZS CISPR 32 Class A, VCCI Class A |
| Design |
|---|
| Weatherproof |
Yes |
| IK code |
IK10+ |
| Form factor |
Dome |
| Product colour |
Silver |
| Mounting type |
Ceiling/wall |
| International Protection (IP) code |
IP66, IP69K |
| Camera |
|---|
| Minimum illumination |
0.07 lx |
| Tilt angle range |
-43 - 80° |
| Camera shutter speed |
1/66500 - 2 s |
| Camera pan control |
Yes |
| Camera tilt control |
Yes |
| Progressive scan |
Yes |
| Image sensor |
|---|
| Sensor type |
CMOS |
| Progressive scan |
Yes |
| Optical sensor size |
25.4 / 1.2 mm (1 / 1.2") |
| Number of sensors |
1 |
| Lens system |
|---|
| Number of lenses |
1 |
| Zoom capability |
Yes |
| Focal length range |
6.2 - 12.9 mm |
| Night vision |
|---|
| Night vision |
Yes |
| LED type |
IR |
| Video |
|---|
| Image quality adjustment |
Brightness, Contrast, Saturation, Sharpness |
| Privacy masking |
Yes |
| Maximum resolution |
3840 x 2160 pixels |
| Video formats supported |
H.264, H.265 |
| Frame rate |
60 fps |
| Video streaming |
Yes |
| Total megapixels |
8 MP |
| Video recording |
Yes |
| Audio |
|---|
| Built-in microphone |
Yes |
| Audio formats supported |
AAC-LC, G.711, G.726, OPUS |
| Audio detection |
Yes |
| Network |
|---|
| Networking standards |
IEEE 802.3at |
| Quality of Service (QoS) support |
Yes |
| Ethernet LAN |
Yes |
| Storage |
|---|
| Card reader integrated |
Yes |
| Built-in HDD |
No |
| Compatible memory cards |
MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Internal memory |
2048 MB |
| Flash memory |
8194 MB |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Connectivity technology |
Wired |
| Security |
|---|
| Alert notification type |
E-mail |
| IP address filtering |
Yes |
| HTTPS encryption |
Yes |
| Active tampering alarm |
Yes |
| Pixel counter |
Yes |
| Human and vehicle targets classification |
Yes |
| Power |
|---|
| Power source type |
PoE |
| Power consumption (max) |
23 W |
| Power consumption (typical) |
9 W |
| Certificates |
|---|
| Certification |
CISPR 35, EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), IEC 62236-4, KS C 9832 Class A, KS C 9835, RCM AS/NZS CISPR 32 Class A, VCCI Class A |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-50 - 60 °C |
| Storage temperature (T-T) |
-40 - 65 °C |
| Operating relative humidity (H-H) |
10 - 100% |
| Storage relative humidity (H-H) |
5 - 95% |
| Packaging content |
|---|
| Number of cameras |
1 |
| Mounting kit |
Yes |
| Mounting brackets included |
Yes |
| Manual |
Yes |
| Drilling template included |
Yes |
