Description
159.7 x 156.7 x 33.8 mm, 884g, RJ45, 802.11a/b/g, PoE, Bluetooth
Key Features
- 1,250 ft coverage
- 600+ connected devices
- WiFi6E (4x4 MIMO)
- Powered using PoE+/PoE++
- (4) GbE ports with (1) PoE output
- 2.5GbE uplink
Description
The sleekest tri-band Access Point in the Industry.Specifications
| Data transmission | |
|---|---|
| Ethernet LAN data rates | 2500 Mbit/s |
| Maximum data transfer rate | 4800 Mbit/s |
| Performance | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Reset button | Yes |
| Number of users | 600 user(s) |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN data rates | 2500 Mbit/s |
| Certification | CE, FCC, IC |
| Maximum data transfer rate | 4800 Mbit/s |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Network | |
| Number of users | 600 user(s) |
| Management features | |
| Quality of Service (QoS) support | Yes |
| Features | |
| 6 GHz | Yes |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Number of users | 600 user(s) |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN data rates | 2500 Mbit/s |
| Maximum data transfer rate | 4800 Mbit/s |
| Bluetooth | Yes |
| MIMO type | Multi User MIMO |
| MIMO | Yes |
| Maximum data transfer rate (2.4 GHz) | 573.5 Mbit/s |
| Maximum data transfer rate (5 GHz) | 4800 Mbit/s |
| Maximum data transfer rate (6 GHz) | 4800 Mbit/s |
| Security | |
| Security algorithms | WPA, WPA-PSK, WPA2, WPA3 |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 4 |
| Power | |
| Power consumption (max) | 21 W |
| Power over Ethernet (PoE) | Yes |
| DC voltage range | 44 - 57 V |
| Design | |
| Housing material | Aluminium, Polycarbonate (PC) |
| Placement | Wall |
| Product colour | White |
| Reset button | Yes |
| LED indicators | Yes |
| Certification | CE, FCC, IC |
| Antenna | |
| Antenna type | Internal |
| Antenna gain level (max) | 5.8 dBi |
| Technical details | |
| Reset button | Yes |
| Certificates | |
| Certification | CE, FCC, IC |
| Indication | |
| LED indicators | Yes |
| Weight & dimensions | |
| Width | 159.7 mm |
| Depth | 33.8 mm |
| Weight | 884 g |
| Height | 159.7 mm |
| Packaging data | |
| Mounting kit | Yes |
| Packaging content | |
| Mounting kit | Yes |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -30 - 60 °C |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
