Description
7 mm, 30 fps, NETD, AGC, PoE/DC
Key Features
- Built-in cybersecurity features; Early fire detection analytics; IP66-, IP67-, IK10- and NEMA 4X -rated; Polygonal temperature monitoring areas; Spot temperature reading
Description
Ideal to improve operational efficiency, this thermometric camera lets you remotely monitor temperatures from -40 °C to 350 °C (-40 °F to 660 °F). You’ll know if your equipment is close to overheating and can act to avoid unwanted downtime. Supporting up to 10 configurable polygonal detection areas, you can monitor for specific temperature levels or change-rates. With early fire detection analytics, it’s possible to monitor early signs of fire with smart filtering of potential false alarms. AXIS Q1961-TE includes built-in cybersecurity features to help safeguard your system. Furthermore, edge-to-edge technology lets you connect network speakers to enable audio alarms.Specifications
| Performance | |
|---|---|
| Number of languages | 19 |
| Languages support | Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, Finnish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Thai, Turkish, Vietnamese |
| Processor model | ARTPEC-8 |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Certification | CSA, UL/cUL, UKCA, CE, KC |
| Thermal sensitivity (NETD) | 40 mK |
| Thermal module | Yes |
| Built-in processor | Yes |
| Design | |
| IK code | IK10 |
| Form factor | Bullet |
| Product colour | White |
| Mounting type | Wall |
| International Protection (IP) code | IP66, IP67 |
| Housing material | Aluminium, Polycarbonate (PC) |
| Camera | |
| Camera pixel size | 17 µm |
| Lens viewing angle, horizontal | 55° |
| Image sensor | |
| Sensor type | Microbolometer |
| Sensor type (thermal module) | Noise equivalent temperature difference (NETD) |
| Lens system | |
| Maximum aperture number | 1.18 |
| Lens diameter | 7 mm |
| Night vision | |
| Night vision | No |
| Video | |
| Privacy masking | Yes |
| Gain control type | Auto |
| Video compression formats | H.264, H.265, M-JPEG |
| Maximum resolution | 384 x 288 pixels |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Video recording | Yes |
| Audio | |
| Audio input channels | 1.0 channels |
| Audio output channels | 1.0 channels |
| Audio system | 1-way |
| Network | |
| Bluetooth | No |
| Ethernet interface type | Gigabit Ethernet |
| Networking standards | IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Storage | |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Internal memory | 2048 MB |
| Flash memory | 8192 MB |
| Ports & interfaces | |
| Terminal block port | Yes |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Connectivity technology | Wired |
| Security | |
| Temperature sensor | Yes |
| Temperature measurement range | -40 - 350 °C |
| Video motion detection | Yes |
| IP address filtering | Yes |
| Active tampering alarm | Yes |
| Password protection | Yes |
| Mirror | Yes |
| Pixel counter | Yes |
| Digest authentication | Yes |
| Temperature measurement accuracy | 5 °C |
| Fire detection | Yes |
| Network access storage (NAS) | Yes |
| Power | |
| Power source type | DC, PoE |
| Power consumption (max) | 12.95 W |
| Power consumption (Power over Ethernet (PoE)) | 4.3 W |
| Power consumption (typical) | 4.1 W |
| DC-in jack | Yes |
| DC output voltage | 10, 12, 15, 16, 24, 28 |
| Certificates | |
| Certification | CSA, UL/cUL, UKCA, CE, KC |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 60 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 100% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Length | 272 mm |
| Diameter | 13.2 cm |
| Weight | 1.4 kg |
| Packaging content | |
| Number of cameras | 1 |
| Manual | Yes |
| Packaging content | Drill template, TORX L-keys, terminal block connectors, connector guard, cable gaskets, owner authentication key |
| Technical details | |
| Temperature measurement range | -40 - 350 °C |
| Other features | |
| Video compression formats | H.264, H.265, M-JPEG |
