4G/LTE (Cat 4), 3G, 2G, 2 SIM cards, IEEE 802.11b/g/n, Access Point (AP), Station (STA), 1 x WAN port, 3 x LAN ports
Description
RUT951 features dual-SIM cellular connectivity combined with Wi-Fi and four Ethernet interfaces to meet the needs of the most varied IoT scenarios. Powered by RutOS, this router offers advanced customization options, automation features, and top-level security for your solution.
Specifications
| Technical details |
|---|
| Mounting |
DIN-rail |
| Device type |
Cellular network router |
| Data network |
2G, 3G, 4G |
| Ethernet LAN features |
|---|
| Ethernet LAN (RJ-45) ports |
3 |
| Supported network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SMNP, MQTT, Wake On Lan (WOL) |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Auto MDI/MDI-X |
Yes |
| Ethernet LAN |
Yes |
| Ethernet LAN interface type |
Fast Ethernet |
| DHCP server |
Yes |
| DHCP client |
Yes |
| Cellular interface |
|---|
| Number of SIM cards |
2 |
| 4G standard |
LTE |
| Network |
|---|
| Supported network protocols |
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SMNP, MQTT, Wake On Lan (WOL) |
| Design |
|---|
| Mounting |
DIN-rail |
| Housing material |
Aluminium, Plastic |
| Device type |
Cellular network router |
| Product colour |
Black |
| Market positioning |
Industrial |
| Reset button |
Yes |
| LED indicators |
Yes |
| Wireless LAN features |
|---|
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Mobile network |
|---|
| Number of SIM cards |
2 |
| Data network |
2G, 3G, 4G |
| Short Message Service (SMS) |
Yes |
| 4G standard |
LTE |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
3 |
| Security |
|---|
| Port forwarding |
Yes |
| Security algorithms |
HTTPS, SSH, SSL/TLS, WEP, WPA-EAP, WPA-PSK, WPA2-Enterprise, WPA2-PSK |
| Network address translation (NAT) |
Yes |
| Firewall |
Yes |
| DMZ support |
Yes |
| Material |
|---|
| Housing material |
Aluminium, Plastic |
| Performance |
|---|
| Operating system installed |
RutOS |
| Built-in processor |
Yes |
| Processor manufacturer |
Mediatek |
| Processor frequency |
0.58 GHz |
| RAM capacity |
0.128 GB |
| RAM type |
DDR2 |
| Management features |
|---|
| Web-based management |
Yes |
| Antenna |
|---|
| Antenna type |
External |
| Antennas quantity |
4 |
| Power |
|---|
| Input voltage |
9 - 30 V |
| Power source type |
DC |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-40 - 75 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Weight |
287 g |
| Width |
110 mm |
| Depth |
100 mm |
| Height |
50 mm |
