4G (LTE), 802.11b/g/n, WAN, LAN, Mediatek 580 MHz MIPS 24KEc, 128MB DDR2, IP30, 125 g
Description
Equipped with 4G LTE, Wi-Fi, and two Ethernet ports, RUT241 offers unstoppable connection continuity with automatic WAN failover. Industrial design, compact size, multiple connection interfaces, and compatibility with RMS make this device an excellent fit in numerous IoT and M2M solutions.
Specifications
| Technical details |
|---|
| Built-in display |
No |
| Mounting |
DIN-rail |
| Device type |
Cellular network router |
| Data network |
2G, 3G, 4G |
| Ethernet LAN features |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Auto MDI/MDI-X |
Yes |
| Ethernet LAN |
Yes |
| Ethernet LAN interface type |
Fast Ethernet |
| Networking standards |
IEEE 802.3, IEEE 802.3u |
| Cellular interface |
|---|
| Number of SIM cards |
1 |
| 4G standard |
LTE |
| 2G bands supported |
900,1800 MHz |
| 3G bands supported |
850,900,2100 MHz |
| 4G bands supported |
2300,2500,2600 MHz |
| Design |
|---|
| Built-in display |
No |
| Mounting |
DIN-rail |
| Housing material |
Aluminium, Plastic |
| Device type |
Cellular network router |
| Product colour |
Black |
| Market positioning |
Industrial |
| Reset button |
Yes |
| LED indicators |
Yes |
| Wireless LAN features |
|---|
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Mobile network |
|---|
| Number of SIM cards |
1 |
| Data network |
2G, 3G, 4G |
| Short Message Service (SMS) |
Yes |
| 4G standard |
LTE |
| 2G bands supported |
900,1800 MHz |
| 3G bands supported |
850,900,2100 MHz |
| 4G bands supported |
2300,2500,2600 MHz |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Security |
|---|
| Port forwarding |
Yes |
| Security algorithms |
HTTPS, SSH, SSL/TLS, WEP, WPA-EAP, WPA-PSK, WPA2-Enterprise, WPA2-PSK |
| Network address translation (NAT) |
Yes |
| Firewall |
Yes |
| DMZ support |
Yes |
| Material |
|---|
| Housing material |
Aluminium, Plastic |
| Performance |
|---|
| Operating system installed |
RutOS |
| Built-in processor |
Yes |
| Processor manufacturer |
Mediatek |
| Processor frequency |
0.58 GHz |
| RAM capacity |
0.128 GB |
| RAM type |
DDR2 |
| Management features |
|---|
| Web-based management |
Yes |
| Antenna |
|---|
| Antenna connector type |
SMA |
| Antenna type |
External |
| Antennas quantity |
3 |
| Power |
|---|
| Power source type |
DC |
| Output voltage |
9 - 30 V |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-40 - 75 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Weight |
125 g |
| Width |
83 mm |
| Depth |
74 mm |
| Height |
25 mm |
