Description
UISP airFiber 60 XR, 422 N at 200 km/h (94.86 lbf at 125 mph), IPX6
It's also equipped with a 5 GHz backup radio for operational redundancy, as well as a Bluetooth radio to simplify setup via the UISP® Mobile app.
Features:
- 5 GHz backup radio
- Link range: 15+ km
- (1) 10G SFP+ port
- Integrated GPS
- Link planning support via the ISP Design Center
Description
Multi-gigabit, 60 GHz bridge designed to create long-distance links and deliver 5.4 Gbps total throughput (2.7 Gbps duplex) over them.It's also equipped with a 5 GHz backup radio for operational redundancy, as well as a Bluetooth radio to simplify setup via the UISP® Mobile app.
Features:
- 5 GHz backup radio
- Link range: 15+ km
- (1) 10G SFP+ port
- Integrated GPS
- Link planning support via the ISP Design Center
Specifications
| Data transmission | |
|---|---|
| Maximum transfer distance | 4000 m |
| Antenna | |
| Antenna gain level (max) | 26 dBi |
| Antenna design | External |
| Wireless LAN features | |
| Modulation | 16-QAM, BPSK, QPSK |
| Antenna gain level (max) | 26 dBi |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 1000 Mbit/s |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ports & interfaces | |
| Ethernet LAN | Yes |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
| Security algorithms | WPA2-PSK |
| Management features | |
| Web-based management | Yes |
| LED indicators | LAN, Power |
| Features | |
| Product type | Network bridge |
| Material | Polycarbonate (PC), Steel |
| Product colour | White |
| Reset button | Yes |
| Network Time Protocol (NTP) client | Yes |
| International Protection (IP) code | IPX6 |
| Power LED | Yes |
| LED indicators | LAN, Power |
| Internal memory | 1024 MB |
| Mounting type | Pole |
| System requirements | |
| Compatible operating systems | Any modern web browser/iOS™ or Android™ based smartphone |
| Power | |
| Power consumption (max) | 24 W |
| Power source type | PoE |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) voltage | 48 V |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 55 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -40 - 131 °F |
| Certificates | |
| Certification | FCC, IC, CE |
| Technical details | |
| Material | Polycarbonate (PC), Steel |
| Product colour | White |
| Operating temperature (T-T) | -40 - 131 °F |
| Internal memory | 1024 MB |
| Quantity per pack | 1 pc(s) |
| Weight & dimensions | |
| Weight | 8.6 kg |
| Width | 779 mm |
| Depth | 664 mm |
| Height | 383 mm |
| Processor | |
| Processor frequency | 1400 MHz |
| Processor manufacturer | Qualcomm |
| Memory | |
| RAM type | DDR3 |
| Indication | |
| Power LED | Yes |
| Packaging content | |
| Manual | Yes |
| Mounting bracket(s) included | Yes |
| Power supply included | Yes |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
