AxisSKU: 02653-001
Price:
€979,39

Description

2 doors, RJ-45, RS485/Wiegand, DC

Key Features

  • Advanced control for two doors; Built-in cybersecurity features; Integrated with Axis and 3rd party solutions; Intelligence on the edge; Versatile installation with plenum rating

Description

This advanced and robust solution includes everything needed to control two doors – all powered by one PoE cable. It offers fast and easy installation on walls. Plus, it’s suitable for plenum spaces. Thanks to intelligence on the edge, it can internally handle all tasks related to door access – even if the network is down. Fully integrated within Axis end-to-end and partner solutions, this scalable product is optimized for both small and large installations. It includes six auxiliary I/Os for easy integration. Plus, it supports flexible authentication using different types of credentials. Furthermore, built-in cybersecurity features prevent unauthorized access and safeguard your system.

Specifications

Technical details
Maximum number of doors 2 door(s)
Case design Housing
Built-in UPS No
Interface RJ-45 / RS-485
Supported network protocols IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSd, HTTP/2, TLSd, QoS Layer 3 DiffServ, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTCP, RTP, SRTP, TCP, UDP, IGMPv1/v2/v3, DHCPv4/v6, ARP, SSH, NTCIP, SIP, LLDP, CDP, MQTT v3.1.1, Syslog, Link-Local address (ZeroConf)
Relay inputs 2
Number of Wiegand readers supported 2
Performance
Number of Wiegand readers supported 2
Internal storage capacity 2 GB
Storage media Flash
Ethernet LAN Yes
Certification EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, KS C 9832 Class A, KS C 9835
Ethernet LAN data rates 10,100 Mbit/s
Wiegand interface Yes
Power
DC voltage range 10.5 - 28 V
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
RS-485 ports 1
Operational conditions
Operating temperature (T-T) -40 - 55 °C
Operating relative humidity (H-H) 20 - 85%
Storage temperature (T-T) -40 - 55 °C
Weight & dimensions
Width 175 mm
Weight 1.2 kg
Height 60 mm
Depth 175 mm
