Description
Super UST 4KE laser display
The EB-810E can be placed just centimetres away from a wall to create bright 4KE images up to 160”. It projects content in stunning clarity and offers a low cost, energy efficient large display solution with a convenient and quick set up.
EB-810E's super-ultra-short-throw lens allows discreet positioning close to the wall, enabling presenters free access without casting shadows.
With 5,000 lumens CLO and 3LCD technology, the EB-810E is bright and vibrant up-to 160", which enables content visibility from all angles and distances. The experience is immersive and it's extremely simple to use.
Versatile wired and wireless connectivity options, including Miracast™ screen mirroring, ensure effortless, multi-device content sharing.
Weighing only 12.3kg, it is highly portable, and the Epson Setting Assistant App makes setup quick and simple. The ideal display solution suitable for different room sizes, combined with flexible installation options.
The EB-810E supports multiple aspect ratios and multi-projector edge-blending for a low cost, seamless, energy efficient ultra-wide display, perfect for video conferencing.
Paired with Epson's Ambient Light Rejection Screen, the EB-810E's image quality could be mistaken for a video wall or LED display, but it is surprisingly affordable and consumes a fraction of the energy.
Description
EB-810E, Epson’s first 4KE super-ultra-short-throw laser display designed for businesses, hybrid working and immersive spacesThe EB-810E can be placed just centimetres away from a wall to create bright 4KE images up to 160”. It projects content in stunning clarity and offers a low cost, energy efficient large display solution with a convenient and quick set up.
EB-810E's super-ultra-short-throw lens allows discreet positioning close to the wall, enabling presenters free access without casting shadows.
With 5,000 lumens CLO and 3LCD technology, the EB-810E is bright and vibrant up-to 160", which enables content visibility from all angles and distances. The experience is immersive and it's extremely simple to use.
Versatile wired and wireless connectivity options, including Miracast™ screen mirroring, ensure effortless, multi-device content sharing.
Weighing only 12.3kg, it is highly portable, and the Epson Setting Assistant App makes setup quick and simple. The ideal display solution suitable for different room sizes, combined with flexible installation options.
The EB-810E supports multiple aspect ratios and multi-projector edge-blending for a low cost, seamless, energy efficient ultra-wide display, perfect for video conferencing.
Paired with Epson's Ambient Light Rejection Screen, the EB-810E's image quality could be mistaken for a video wall or LED display, but it is surprisingly affordable and consumes a fraction of the energy.
Specifications
| Projector | |
|---|---|
| Projector native resolution | 1080p (1920x1080) |
| Native aspect ratio | 16:9 |
| Screen size compatibility | 2032 - 4064 mm (80 - 160") |
| Contrast ratio (typical) | 2500000:1 |
| Zoom ratio | 1.35:1 |
| Vertical scan range | 192 - 240 Hz |
| Projection technology | 3LCD |
| Projector brightness | 5000 ANSI lumens |
| Smart projector | No |
| Lamps | |
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
| Light source | |
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
| Lens system | |
| Fixed focal length | 2.3 mm |
| Zoom ratio | 1.35:1 |
| Focus | Manual |
| Throw ratio | 0.16 - 0.40:1 |
| F-number (relative aperture) | 1.8 |
| Scanning frequency | |
| Vertical scan range | 192 - 240 Hz |
| Video | |
| Video colour modes | Blackboard, Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation |
| Analog signal format system | Not supported |
| Full HD | Yes |
| 3D | No |
| Audio | |
| Built-in speaker(s) | No |
| Ports & interfaces | |
| HDBaseT port | Yes |
| HDMI ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 2 |
| Serial interface type | RS-232C |
| DVI port | No |
| Service port type | USB Type-B |
| USB 2.0 Type-A ports quantity | 2 |
| Network | |
| Smart TV | No |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Ethernet LAN (RJ-45) ports | 1 |
| Miracast | Yes |
| Storage | |
| Card reader integrated | No |
| Sound emission | |
| Noise level | 35 dB |
| Noise level (economic mode) | 26 dB |
| Technical details | |
| Product colour | White |
| Performance | |
| Market positioning | Business |
| Password protection | Yes |
| Vertical scan range | 192 - 240 Hz |
| Noise level | 35 dB |
| Noise level (economic mode) | 26 dB |
| Features | |
| Interactive | No |
| Password protection | Yes |
| Noise level | 35 dB |
| Noise level (economic mode) | 26 dB |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG) |
| High Dynamic Range (HDR) supported | Yes |
| Multimedia | |
| Built-in speaker(s) | No |
| Design | |
| Market positioning | Business |
| Product type | Ultra short throw projector |
| Cable lock slot type | Kensington |
| Product colour | White |
| Cable lock slot | Yes |
| Placement | Ceiling, Desktop, Wall |
| Display | |
| Built-in display | No |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (max) | 380 W |
| Power source | AC |
| Power consumption (typical) | 290 W |
| Power consumption (PowerSave) | 0.4 W |
| Power consumption (economy mode) | 286 W |
| Security | |
| Cable lock slot type | Kensington |
| Cable lock slot | Yes |
| Operational conditions | |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | -10 - 60 °C |
| Weight & dimensions | |
| Weight | 12.5 kg |
| Width | 695 mm |
| Depth | 341 mm |
| Height | 156 mm |
| Packaging content | |
| Remote control included | Yes |
| Cables included | AC |
| Batteries included | Yes |
| Other features | |
| F-number (relative aperture) | 1.8 |
| Power consumption (economy mode) | 286 W |
