Description
93 x 40 x 36.5 mm, 82 g, IP55, RJ45, BLE 4.1, 48V DC
Key Features
- Unlock using an NFC card or UniFi Identity mobile app
- Additional handwave unlock functionality
- Entry and exit greeting messages
- Connects to UniFi Access Hub using PoE
- IP55 weather resistance (-30 to 45° C)
Description
Empower employees with a wide variety of unlock options suitable for any weather conditions.Specifications
| Technical details | |
|---|---|
| RFID frequency | 13.56 MHz |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Type | Basic access control reader |
| Fingerprint reader | No |
| Contactless working distance | 3 cm |
| Certification | CE, FCC, IC |
| Access code reader | No |
| Access chip/card reader type | Contactless |
| Access chip/card reader | Yes |
| Product colour | White, Black |
| Housing material | Glass, Polycarbonate (PC) |
| International Protection (IP) code | IP55 |
| Near Field Communication (NFC) | Yes |
| LED indicators | Status |
| Bluetooth version | 4.1 |
| Bluetooth | Yes |
| Display | |
| Built-in display | No |
| Ports & interfaces | |
| Ethernet LAN data rates | 10,100 Mbit/s |
| PC connected | No |
| Contactless working distance | 3 cm |
| Near Field Communication (NFC) | Yes |
| Bluetooth version | 4.1 |
| Bluetooth | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| Power over Ethernet (PoE) | Yes |
| DC voltage range | 48 V |
| Power consumption (max) | 6 W |
| Weight & dimensions | |
| Width | 40 mm |
| Weight | 82 g |
| Height | 93 mm |
| Depth | 36.5 mm |
| Packaging content | |
| Mounting bracket(s) included | Yes |
| Certificates | |
| Certification | CE, FCC, IC |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
