Black Box ACX1T-12A-C AV extender AV transmitter

DKM Compact - Transmitter, CATx, 140m, 1x SingleLink DVI-D, 4x USB HID

Description

Use these extender units with your DKM switching system and extend high-quality digital graphics, USB peripherals, audio and serial up to 10 km away

- For use with ServSwitch DKM, DKM FX and DKM FXC digital cross point switching system.
- Distances of up to 140m over CATx, 800m over multi-mode and 10km over single-mode.
- Video resolution of 2048 x 1152, 60 Hz.
- 24Bit color depth.
- Single- or dual-head DVI-D plus options for VGA sources.
- Optional fibre DVI high-speed models with 2.5 Gbps of video bandwidth for demanding applications.
- USB HID keyboard/mouse interface with True USB Emulation supporting extended functions.
- Options for analog and digital audio, serial and USB 2.0.
- Local monitoring with separate splitter cable.
- Compact housings in a space saving design.
- Options for 19" and DIN-rail mounting.
- Warranty: 1 year, options for extension

Specifications

Features
Type	AV transmitter
Maximum resolution	2048 x 1152 pixels
Maximum transfer distance	140 m
Product colour	Black
Technical details
Type	AV transmitter
Maximum resolution	2048 x 1152 pixels
Maximum transfer distance	140 m
Product colour	Black
Ports & interfaces
USB ports quantity	4
RJ-45 input ports	1
DVI input ports	1
DC-in jack	Yes
