Description
Samsung QM32C, Digital signage flat panel, 81.3 cm (32"), LCD, 1920 x 1080 pixels, Wi-Fi, 24/7
Description
Samsung QM32C. Product design: Digital signage flat panel. Display diagonal: 81.3 cm (32"), Display technology: LCD, Display resolution: 1920 x 1080 pixels, Display brightness: 400 cd/m², HD type: Full HD. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: Tizen. Product colour: BlackSpecifications
| Display | |
|---|---|
| LED backlight | Yes |
| Panel type | IPS |
| Dynamic contrast ratio marketing name | Mega Contrast |
| Touchscreen | No |
| Display technology | LCD |
| Display diagonal | 81.3 cm (32") |
| Display resolution | 1920 x 1080 pixels |
| Display brightness | 400 cd/m² |
| HD type | Full HD |
| Response time | 8 ms |
| Contrast ratio (typical) | 1200:1 |
| Viewing angle, horizontal | 178° |
| Viewing angle, vertical | 178° |
| Pixel pitch | 0.36375 x 0.36375 mm |
| Vertical scan range | 48 - 75 Hz |
| Horizontal scan range | 30 - 81 kHz |
| Haze rate | 1% |
| RGB colour space | NTSC |
| Pixel frequency (max) | 148.5 MHz |
| Ports & interfaces | |
| Remote (IR) input | 1 |
| USB port | Yes |
| HDMI version | 1.4 |
| Infrared data port | Yes |
| Wi-Fi | Yes |
| DisplayPorts quantity | 0 |
| Ethernet LAN | Yes |
| HDMI ports quantity | 3 |
| DVI port | No |
| Ethernet LAN (RJ-45) ports | 1 |
| RS-232 interface | Yes |
| USB ports quantity | 2 |
| HDMI input ports quantity | 3 |
| Design | |
| Product design | Digital signage flat panel |
| Placement supported | Indoor |
| Bezel width (top) | 1.15 cm |
| Bezel width (side) | 1.15 cm |
| Bezel width (bottom) | 1.15 cm |
| Product colour | Black |
| Panel mounting interface | 100 x 100 mm |
| Certification | Class B 60950-1, 62368-1 |
| VESA mounting | Yes |
| Mounting type | Wall |
| Screen shape | Flat |
| Bezel colour | Charcoal Black |
| Performance | |
| Operating hours (hours/days) | 24/7 |
| HDCP | Yes |
| HDCP version | 2.2 |
| Wi-Fi | Yes |
| Power | |
| Power consumption (sleep) | 0.5 W |
| Power consumption (typical) | 55 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50-60 Hz |
| Computer system | |
| Computer system | Yes |
| Computer system type | System on Chip (SoC) |
| Operating system installed | Tizen |
| Built-in processor | Yes |
| Operating system version | 7.0 |
| Weight & dimensions | |
| Display width | 727.3 mm |
| Display depth | 28.5 mm |
| Display height | 421.9 mm |
| Display weight | 5.2 kg |
| Packaging data | |
| Package width | 817 mm |
| Package depth | 119 mm |
| Package height | 507 mm |
| Package weight | 6.9 kg |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Certificates | |
| Certification | Class B 60950-1, 62368-1 |
| Technical details | |
| VESA mounting | Yes |
| Panel type | IPS |
| RJ-45 input ports | 1 |
| RS-232 output ports | 1 |
| RS-232 input ports | 1 |
| Audio out (mini jack) | 1 |
| Thin Client | |
| Operating system installed | Tizen |
| Other features | |
| Panel type | IPS |
| RJ-45 input ports | 1 |
| RS-232 output ports | 1 |
| RS-232 input ports | 1 |
| Wi-Fi | Yes |
| Flash memory | 8000 MB |
| Display technology | LCD |
| Bluetooth | Yes |
| Bezel width (top) | 1.15 cm |
| Bezel width (side) | 1.15 cm |
| Bezel width (bottom) | 1.15 cm |
| Optional features | STN-L3200C |
