Description
Neomounts WL70-440BL11 Monitor/TV mount wall - 17-32" - 2-9 kg - VESA 75x75-100x100 - d 9-38 cm - gas spring - full motion - black
The WL70-440BL11 has a depth of 9-38 cm and is suitable for screens that meet VESA hole pattern 75x75 to 100x100 mm.
The mount can be easily adjusted in height using the gas spring. The cable management system allows you to route and secure any loose cables at the back of the screen. Additionally, the mount features an Easy-release VESA, that allows you to attach the TV in a wink of an eye.
Description
The Neomounts WL70-440BL11 is a full motion wall mount for flat screens up to 32" with a maximum weight capacity of 9 kg. The versatile tilt (135°), rotate (360°) and swivel (180°) technology allows you to create the optimum viewing angle.The WL70-440BL11 has a depth of 9-38 cm and is suitable for screens that meet VESA hole pattern 75x75 to 100x100 mm.
The mount can be easily adjusted in height using the gas spring. The cable management system allows you to route and secure any loose cables at the back of the screen. Additionally, the mount features an Easy-release VESA, that allows you to attach the TV in a wink of an eye.
Specifications
| Mounting | |
|---|---|
| Maximum weight capacity (per display) | 9 kg |
| Mounting type | Wall |
| Minimum screen size | 43.2 cm (17") |
| Panel mounting interface | 100 x 100,75 x 75 mm |
| Number of displays supported | 1 |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 100 x 100 mm |
| Maximum screen size | 81.3 cm (32") |
| Maximum weight capacity | 9 kg |
| Ergonomics | |
| Height adjustment | Yes |
| Height adjustment range | 0 - 250 mm |
| Cable management | Yes |
| Tilt angle range | -45 - 90° |
| Swivel angle range | 0 - 180° |
| Swivel angle | 180° |
| Angle of rotation | 360° |
| Distance to the wall (min) | 9 cm |
| Distance to the wall (max) | 9 mm |
| Height adjustment type | Gas spring |
| Rotating | Yes |
| Tilt adjustment | Yes |
| Swivelling | Yes |
| Technical details | |
| Cable management | Yes |
| Angle of rotation | 360° |
| Number of displays supported | 1 |
| Distance to the wall (min) | 9 cm |
| Distance to the wall (max) | 9 mm |
| Product colour | Black |
| Mounting type | Wall |
| Country of origin | China |
| Package net weight | 1.7 kg |
| Master (outer) case net weight | 1.3 kg |
| Quantity per pack | 1 pc(s) |
| Design | |
| Cable management | Yes |
| Product colour | Black |
| Housing material | Steel |
| Weight & dimensions | |
| Width | 117 mm |
| Depth | 315 mm |
| Height | 321 mm |
| Weight | 1.28 kg |
| Depth (max) | 31.5 cm |
| Packaging data | |
| Package width | 195 mm |
| Package depth | 440 mm |
| Package height | 90 mm |
| Package weight | 1.7 kg |
| Logistics data | |
| Master (outer) case width | 195 mm |
| Master (outer) case length | 440 mm |
| Master (outer) case height | 90 mm |
| Master (outer) case gross weight | 1.7 kg |
| Products per master (outer) case | 1 pc(s) |
| Master (outer) case net weight | 1.3 kg |
| Products per pallet (EU) | 108 pc(s) |
| Harmonized System (HS) code | 7326909890 |
| Other features | |
| Mounting type | Wall |
| Mounting | Screws |
| Minimum weight | 2 kg |
| Country of origin | China |
