Neomounts FPMA-DCB100DBLACK Dual crossbar monitor arm - 10-27" - 0-10 kg/screen - black
Neomounts versatile tilt (+45°/-45°), rotate (360°) and swivel (30°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The mount is manually height adjustable from 0 to 45 centimetres. The cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.
Neomounts FPMA-DCB100DBLACK has a crossbar with two monitor holders with one pivot point and is suitable for screens up to 27". The weight capacity of this product is 10 kg per screen. The desk mount is suitable for screens that meet VESA hole pattern 75x75 or 100x100mm. Different hole patterns can be covered using Neomounts VESA adapter plates. The pole of the desk mount has a diameter of 35 mm.
By using an ergonomic mount neck- and back complaints can be avoided. Ideal for use in offices and on counters or in a reception area. This mount is the ultimate save spacer on your desk.
All installation material is included with the product.
Description
The Neomounts desk mount, model FPMA-DCB100DBLACK is a tilt-, swivel and rotatable desk mount for 2 flat screens up to 27". This dual crossbar mount is a great choice for space saving placement on desks using a desk clamp or desk grommet.Neomounts versatile tilt (+45°/-45°), rotate (360°) and swivel (30°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The mount is manually height adjustable from 0 to 45 centimetres. The cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.
Neomounts FPMA-DCB100DBLACK has a crossbar with two monitor holders with one pivot point and is suitable for screens up to 27". The weight capacity of this product is 10 kg per screen. The desk mount is suitable for screens that meet VESA hole pattern 75x75 or 100x100mm. Different hole patterns can be covered using Neomounts VESA adapter plates. The pole of the desk mount has a diameter of 35 mm.
By using an ergonomic mount neck- and back complaints can be avoided. Ideal for use in offices and on counters or in a reception area. This mount is the ultimate save spacer on your desk.
All installation material is included with the product.
Specifications
| Mounting | |
|---|---|
| Maximum weight capacity (per display) | 10 kg |
| Desk thickness (max) | 9 cm |
| Minimum screen size | 25.4 cm (10") |
| Panel mounting interface | 75 x 75 mm |
| Number of displays supported | 2 |
| Mounting type | Desk |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 100 x 100 mm |
| Mounting | Clamp/Grommet |
| Maximum screen size | 68.6 cm (27") |
| Ergonomics | |
| Depth adjustment range | 0 - 80 mm |
| Height adjustment | Yes |
| Height adjustment range | 0 - 450 mm |
| Pivot angle | -180 - 180° |
| Swivel angle range | -15 - 15° |
| Swivel angle | 30° |
| Tilt angle range | -45 - 45° |
| Angle of rotation | 360° |
| Number of pivot points | 1 |
| Height adjustment type | Manual |
| Rotating | Yes |
| Tilt adjustment | Yes |
| Swivelling | Yes |
| Design | |
| Product colour | Black |
| Housing material | Steel |
| Technical details | |
| Number of pivot points | 1 |
| Mounting type | Desk |
| Product colour | Black |
| Weight & dimensions | |
| Depth | 80 mm |
| Height | 450 mm |
| Weight | 4.03 kg |
| Package width | 166 mm |
| Package depth | 120 mm |
| Package height | 512 mm |
| Package weight | 5.3 kg |
| Packaging data | |
| Package width | 166 mm |
| Package depth | 120 mm |
| Package height | 512 mm |
| Package weight | 5.3 kg |
| Logistics data | |
| Master (outer) case width | 345 mm |
| Master (outer) case length | 255 mm |
| Master (outer) case height | 525 mm |
| Master (outer) case gross weight | 21.1 kg |
| Products per master (outer) case | 4 pc(s) |
| Country of origin | China |
| Products per pallet (EU) | 100 pc(s) |
| Master (outer) case net weight | 16.5 kg |
| Harmonized System (HS) code | 7326909890 |
| Other features | |
| Mounting type | Desk |
| Mounting | Clamp/Grommet |
| Country of origin | China |
