Description
Neomounts PLASMA-W200BLACK Tiltable TV mount wall - 37-85" - max 100 kg - VESA 200x200-865x480 - d 8,3 cm - lockable (excl. lock) - black
Neomounts' tilt (30°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. Depth of this mount is 7 centimetres.
Neomounts PLASMA-W200BLACK is suitable for screens up to 85" (216 cm). The weight capacity of this product is 100 kg each screen. The wall mount is suitable for screens that meet VESA hole pattern 200x200 to 865x480mm. Different hole patterns can be covered using Neomounts VESA adapter plates.
Create a clean design ambiance for your flat screen TV in the living room, bedroom or home cinema.
All installation material is included with the product.
Description
The Neomounts wall mount, model PLASMA-W200BLACK is a tiltable wall mount for flat screens up to 85" (216 cm). This mount is a great choice when you want the ultimate viewing flexibility with your flat screen. Depth of this mount is 8,3 centimetres.Neomounts' tilt (30°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. Depth of this mount is 7 centimetres.
Neomounts PLASMA-W200BLACK is suitable for screens up to 85" (216 cm). The weight capacity of this product is 100 kg each screen. The wall mount is suitable for screens that meet VESA hole pattern 200x200 to 865x480mm. Different hole patterns can be covered using Neomounts VESA adapter plates.
Create a clean design ambiance for your flat screen TV in the living room, bedroom or home cinema.
All installation material is included with the product.
Specifications
| Mounting | |
|---|---|
| Maximum weight capacity (per display) | 100 kg |
| Mounting type | Wall |
| Minimum screen size | 94 cm (37") |
| Panel mounting interface | 800 x 400 mm |
| Number of displays supported | 1 |
| Minimum VESA mount | 200 x 200 mm |
| Maximum VESA mount | 865 x 480 mm |
| Maximum screen size | 2.16 m (85") |
| Maximum weight capacity | 100 kg |
| Ergonomics | |
| Tilt angle range | 0 - 30° |
| Distance to the wall (max) | 8.3 cm |
| Tilt adjustment | Yes |
| Technical details | |
| Number of displays supported | 1 |
| Distance to the wall (max) | 8.3 cm |
| Product colour | Black |
| Mounting type | Wall |
| Country of origin | China |
| Package net weight | 6.25 kg |
| Master (outer) case net weight | 12.5 kg |
| Lockable | Padlock not included |
| Design | |
| Product colour | Black |
| Housing material | Steel |
| Weight & dimensions | |
| Width | 904 mm |
| Depth | 83 mm |
| Height | 500 mm |
| Weight | 5.39 kg |
| Packaging data | |
| Package width | 235 mm |
| Package depth | 85 mm |
| Package height | 930 mm |
| Package weight | 6.3 kg |
| Logistics data | |
| Master (outer) case width | 960 mm |
| Master (outer) case length | 185 mm |
| Master (outer) case height | 250 mm |
| Master (outer) case gross weight | 13.5 kg |
| Products per master (outer) case | 2 pc(s) |
| Master (outer) case net weight | 12.5 kg |
| Products per pallet (EU) | 48 pc(s) |
| Harmonized System (HS) code | 7326909890 |
| Other features | |
| Mounting type | Wall |
| Country of origin | China |
