Description
Neomounts FPMA-D510BLACK Single monitor arm - 10-32" - 0-8 kg - black
Neomounts versatile tilt (90°), rotate (360°) and swivel (180°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. Cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.
Neomounts FPMA-D510BLACK has one pivot points and is suitable for screens up to 32". The weight capacity of this product is 8 kg. The desk mount is suitable for screens that meet VESA hole pattern 75x75 or 100x100mm. Different hole patterns can be covered using Neomounts VESA adapter plates.
By using an ergonomic mount neck- and back complaints can be avoided. Ideal for use in offices and on counters or in a reception area.
All installation material is included with the product.
Description
The Neomounts desk mount, model FPMA-D510BLACK is a tilt-, swivel and rotatable desk mount for flat screens up to 32". This mount is a great choice for space saving placement on desks using a desk clamp or grommet mount.Neomounts versatile tilt (90°), rotate (360°) and swivel (180°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. Cable management conceals and routes cables from mount to flat screen. Hide your cables to keep the workplace nice and tidy.
Neomounts FPMA-D510BLACK has one pivot points and is suitable for screens up to 32". The weight capacity of this product is 8 kg. The desk mount is suitable for screens that meet VESA hole pattern 75x75 or 100x100mm. Different hole patterns can be covered using Neomounts VESA adapter plates.
By using an ergonomic mount neck- and back complaints can be avoided. Ideal for use in offices and on counters or in a reception area.
All installation material is included with the product.
Specifications
| Mounting | |
|---|---|
| Maximum weight capacity (per display) | 8 kg |
| Desk thickness (max) | 7.5 cm |
| Minimum screen size | 25.4 cm (10") |
| Panel mounting interface | 75 x 75 mm |
| Number of displays supported | 1 |
| Mounting type | Desk |
| Minimum VESA mount | 75 x 75 mm |
| Maximum VESA mount | 100 x 100 mm |
| Mounting | Clamp/Grommet |
| Maximum weight capacity | 8 kg |
| Maximum screen size | 81.3 cm (32") |
| Ergonomics | |
| Cable management | Yes |
| Depth adjustment range | 0 - 88 mm |
| Height adjustment | Yes |
| Height adjustment range | 0 - 425 mm |
| Swivel angle | 180° |
| Tilt angle range | 0 - 90° |
| Angle of rotation | 360° |
| Height adjustment type | Manual |
| Rotating | Yes |
| Tilt adjustment | Yes |
| Swivelling | Yes |
| Design | |
| Product colour | Black |
| Housing material | Steel |
| Technical details | |
| Mounting type | Desk |
| Product colour | Black |
| Cable management | Yes |
| Weight & dimensions | |
| Depth | 88 mm |
| Height | 425 mm |
| Weight | 2.78 kg |
| Package width | 120 mm |
| Package depth | 110 mm |
| Package height | 489 mm |
| Package weight | 3.3 kg |
| Package net weight | 3.3 kg |
| Packaging data | |
| Package width | 120 mm |
| Package depth | 110 mm |
| Package height | 489 mm |
| Package weight | 3.3 kg |
| Package net weight | 3.3 kg |
| Clamp included | Yes |
| Packaging content | |
| Clamp included | Yes |
| VESA mount included | Yes |
| Logistics data | |
| Master (outer) case width | 260 mm |
| Master (outer) case length | 350 mm |
| Master (outer) case height | 505 mm |
| Master (outer) case gross weight | 19.6 kg |
| Products per master (outer) case | 6 pc(s) |
| Country of origin | China |
| Products per pallet (EU) | 144 pc(s) |
| Master (outer) case net weight | 19.6 kg |
| Harmonized System (HS) code | 7326909890 |
| Other features | |
| Mounting type | Desk |
| Mounting | Clamp/Grommet |
| Country of origin | China |
