Description
DT, 203 dpi, 90 mm/s, Li-Ion, 2600 mAh, USB V2.0 FS, Serial, Bluetooth, Transmissive sensor, iOS
4 inch Thermal
mPOS Mobile Printer
Key Features
- ∙ iPad, iPhone, iOS® mobile printer (MFi certified, iOS® SDK supported)
- ∙ Android mobile printer (Android SDK supported)
- ∙ Linerless mobile label printer (optional)
- ∙ Bluetooth, WiFi connectivity
Description
Compact and Rugged4 inch Thermal
mPOS Mobile Printer
Specifications
| Printing | |
|---|---|
| Type | Mobile printer |
| Print technology | Direct thermal |
| Print speed | 90 mm/sec |
| Maximum resolution | 203 x 203 DPI |
| Performance | |
| Linear (1D) barcodes supported | Codabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, U.P.C. |
| Type | Mobile printer |
| Print technology | Direct thermal |
| Print speed | 90 mm/sec |
| Maximum resolution | 203 x 203 DPI |
| Paper handling | |
| Supported paper width | 112 mm |
| Printing media thickness | 57 µm |
| Maximum roll diameter | 5.7 cm |
| Maximum printing width | 10.4 cm |
| Ports & interfaces | |
| Standard interfaces | Serial, USB 2.0 |
| Connectivity technology | Wired & Wireless |
| USB 2.0 ports quantity | 1 |
| Serial ports quantity | 1 |
| Bluetooth | Yes |
| USB port | Yes |
| Serial interface | Yes |
| Network | |
| Ethernet LAN | No |
| Wi-Fi | No |
| Print technology | |
| Type | Mobile printer |
| Print technology | Direct thermal |
| Print speed | 90 mm/sec |
| Print quality | |
| Maximum resolution | 203 x 203 DPI |
| Maximum printing width | 10.4 cm |
| Technical details | |
| Linear (1D) barcodes supported | Codabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, U.P.C. |
| Maximum printing width | 10.4 cm |
| Product colour | Black |
| Harmonized System (HS) code | 84433210 |
| Features | |
| Linear (1D) barcodes supported | Codabar, Code 128, Code 39, Code 93, EAN-13, EAN-8, U.P.C. |
| Product colour | Black |
| Design | |
| Product colour | Black |
| Power | |
| Battery voltage | 7.4 V |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery recharge time | 4 h |
| Operational conditions | |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating temperature (T-T) | -15 - 50 °C |
| Operating relative humidity (H-H) | 10 - 80% |
| Weight & dimensions | |
| Width | 143 mm |
| Depth | 138 mm |
| Height | 66 mm |
| Weight | 242 g |
| Packaging data | |
| Cables included | AC |
| Packaging content | |
| Cables included | AC |
| Quick start guide | Yes |
| Logistics data | |
| Harmonized System (HS) code | 84433210 |
