Description
1/2.8" CMOS, 1920x1080px, 2MP, 50m IR, 60 fps, 12V PoE
Make faster, informed decisions with a camera that can differentiate normal activity vs. suspicious behavior and tell you when you need to step in.
Coverage anytime, anywhere
Rain, sleet or shine, our camera is ready for the challenge with IP66/67, Type 4K and IK10 ratings.
Real-time threat detection
Quickly identify situations requiring your attention with enhanced object detection and classification.
Elevate your camera
Reduce maintenance costs using cloud-based machine learning to eliminate processes of manually checking on your cameras.
Seamless integrations
This modular camera is built on an open system for straightforward installation and configuration.
Key Features
- Detect objects with Smart Analytics
- Flexible lens options
- See in bright and low-light
- Easy to deploy
- Protect against cyber attacks
- Integrates with your ONVIF-conformant VMS
Description
Impeccable imaging for advanced insightsMake faster, informed decisions with a camera that can differentiate normal activity vs. suspicious behavior and tell you when you need to step in.
Coverage anytime, anywhere
Rain, sleet or shine, our camera is ready for the challenge with IP66/67, Type 4K and IK10 ratings.
Real-time threat detection
Quickly identify situations requiring your attention with enhanced object detection and classification.
Elevate your camera
Reduce maintenance costs using cloud-based machine learning to eliminate processes of manually checking on your cameras.
Seamless integrations
This modular camera is built on an open system for straightforward installation and configuration.
Specifications
| Performance | |
|---|---|
| Infrared (IR) cut-off filter | Yes |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Certification | UL/CSA/EN/IEC 62368-1, IEC 62471, FCC Part 15 Subpart B (Class B), IC ICES-003 (Class B), EN 55032 (Class B), EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 50130-4, EN 50121-4 |
| Dynamic range | 126 dB |
| Design | |
| Weatherproof | Yes |
| IK code | IK10 |
| Form factor | Bullet |
| Product colour | Black, White |
| Mounting type | Wall |
| Protection features | Weatherproof |
| International Protection (IP) code | IP66, IP67 |
| Housing material | Aluminium |
| Camera | |
| Minimum illumination | 0.005 lx |
| Tilt angle range | -90 - 90° |
| Pan range | -175 - 175° |
| White balance | Auto, Manual |
| Angle of rotation | 350° |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/7.5 - 1/30000 s |
| Lens viewing angle, horizontal | 101° |
| Lens viewing angle, vertical | 53° |
| Number of Privacy masking areas | 64 |
| Image sensor | |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Number of sensors | 1 |
| Lens system | |
| Number of lenses | 1 |
| Maximum aperture number | 1.6 |
| Auto focus | Yes |
| Focus | Motorized |
| Zoom capability | Yes |
| Focal length range | 3.4 - 10.5 mm |
| Night vision | |
| Night vision | Yes |
| Night vision distance | 50 m |
| LED type | IR |
| Infra-red wavelength | 850 nm |
| Video | |
| Noise reduction | Yes |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | 3D noise reduction |
| Maximum resolution | 1920 x 1080 pixels |
| Video formats supported | H.264, H.265, M-JPEG |
| Supported graphics resolutions | 512 x 288, 512 x 384, 640 x 360, 640 x 480 (VGA), 768 x 432, 800 x 600 (SVGA), 960 x 720, 1280 x 720 (HD 720), 1280 x 960, 1440 x 1080, 1920 x 1080 (HD 1080) |
| Frame rate | 60 fps |
| Video streaming | Yes |
| Total megapixels | 2 MP |
| Video intelligence analytic | Yes |
| Audio | |
| Sample rate | 8 kHz |
| Signal-to-Noise Ratio (SNR) | 50 dB |
| Audio formats supported | G.711, PCM |
| Network | |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.3af |
| Streaming method | Multicast |
| Ethernet LAN | Yes |
| Supported network protocols | IPv6, IPv4, HTTP, HTTPS, SOAP, DNS, NTP, RTSP, RTCP, RTP, TCP, UDP, IGMPv3, ICMP, DHCP, Zeroconf, HSTS, RTP/UDP, RTP/UDP multicast, RTP/RTSP/TCP, RTP/RTSP/HTTP/TCP, RTP/RTSP/HTTPS/TCP, HTTP, SRTP, SNMP v2c, SNMP v3 |
| Storage | |
| Maximum memory card size | 1.5 TB |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 512 MB |
| RAM capacity | 1000 MB |
| Ports & interfaces | |
| USB port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security | |
| Privacy protection | Yes |
| Intelligent Video Surveillance (IVS) system features | Line crossing detection, Missing object, Moving object, Region entrance detection, Region exiting detection |
| Video motion detection | Yes |
| HTTPS encryption | Yes |
| Password protection | Yes |
| Digest authentication | Yes |
| Power | |
| Power source type | Battery, PoE |
| Power consumption (Power over Ethernet (PoE)) | 13 W |
| Battery technology | Lithium |
| Battery | |
| Battery technology | Lithium |
| Certificates | |
| Certification | UL/CSA/EN/IEC 62368-1, IEC 62471, FCC Part 15 Subpart B (Class B), IC ICES-003 (Class B), EN 55032 (Class B), EN 61000-6-3, EN 61000-3-2, EN 61000-3-3, EN 55035, EN 61000-6-1, EN 50130-4, EN 50121-4 |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 60 °C |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions | |
| Width | 126 mm |
| Depth | 294 mm |
| Height | 104 mm |
| Weight | 1.31 kg |
| Sustainability | |
| Compliance certificates | BIS, CE, KC, Norma Oficial Mexicana (NOM), RCM, RoHS, UKCA, UL, cUL |
| Packaging content | |
| Number of cameras | 1 |
| Technical details | |
| Compliance certificates | BIS, CE, KC, Norma Oficial Mexicana (NOM), RCM, RoHS, UKCA, UL, cUL |
| Other features | |
| Focus | Motorized |
