10 Gbps uplink/downlink, up to 20 km, 1x XGS-PON port, 1x 10GbE RJ45 LAN port, UV-stabilized polycarbonate, 256 MB DDR, 32 MB NOR, 8W, black/white
Key Features
- (1) XGS-PON port
- (1) 10GbE RJ45 LAN port
Description
An optical network unit that can deliver 10 Gbps uplink/downlink speeds over distances up to 20 km.
Specifications
| Network |
|---|
| Ethernet LAN data rates |
100,1000,2500,5000,10000 Mbit/s |
| Ethernet interface type |
2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| Maximum data transfer rate |
10000 Mbit/s |
| Fiber optic connector |
SC/APC |
| Performance |
|---|
| Maximum transfer distance |
20000 m |
| Tx power (min) |
4 dBmW |
| Tx power (max) |
9 dBmW |
| Rx power (min) |
-9 dBmW |
| Rx power (max) |
-26 dBmW |
| Features |
|---|
| Reset button |
Yes |
| Housing material |
Polycarbonate (PC) |
| LED indicators |
Yes |
| Product colour |
Black, White |
| Internal |
No |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Fiber ports quantity |
1 |
| Fiber optic connector |
SC/APC |
| Power |
|---|
| Power consumption (max) |
8 W |
| Input current |
3 A |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Weight & dimensions |
|---|
| Width |
100 mm |
| Depth |
100 mm |
| Weight |
220 g |
| Height |
27 mm |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-15 - 45 °C |
| Operating relative humidity (H-H) |
10 - 95% |
| Technical details |
|---|
| Housing material |
Polycarbonate (PC) |
| Maximum transfer distance |
20000 m |
| Tx power (min) |
4 dBmW |
| Tx power (max) |
9 dBmW |
| Rx power (min) |
-9 dBmW |
| Rx power (max) |
-26 dBmW |
| Internal |
No |
| Sustainability compliance |
Yes |
| Compliance certificates |
CE, Federal Communications Commission (FCC), UKCA |
| Indication |
|---|
| LED indicators |
Yes |
| Design |
|---|
| Housing material |
Polycarbonate (PC) |
| LED indicators |
Yes |
| Product colour |
Black, White |
| Internal |
No |
| Management features |
|---|
| Reset button |
Yes |
| Colour |
|---|
| Product colour |
Black, White |
| Certificates |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC), UKCA |
