Description
BLE 4.1, PoE, 1x 10/100 MbE RJ45 port, 48V DC, 5W, Proximity sensor, Polycarbonate, glass, IP55, black
Key Features
- Unlock using an NFC card or UniFi Identity mobile app
- Additional handwave unlock functionality
- Entry and exit greeting messages
- Connects to UniFi Access Hub using PoE
- IP55 weather resistance (-30 to 45° C)
Description
Compact, second-generation NFC card reader and request-to-exit device that supports hand-wave door unlocking.Specifications
| Technical details | |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Type | Basic access control reader |
| Authentication type | Access chip/card |
| Fingerprint reader | No |
| Access code reader | No |
| Access chip/card reader | Yes |
| Product colour | Black |
| Housing material | Glass, Polycarbonate (PC) |
| International Protection (IP) code | IP55 |
| Near Field Communication (NFC) | Yes |
| LED indicators | Status |
| Bluetooth version | 4.1 |
| Bluetooth | Yes |
| Sustainability compliance | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Display | |
| Built-in display | No |
| Camera | |
| Front camera | No |
| Performance | |
| Built-in speaker(s) | Yes |
| Number of speakers | 1 |
| Speaker power | 0.7 W |
| Ports & interfaces | |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Near Field Communication (NFC) | Yes |
| Bluetooth version | 4.1 |
| Bluetooth | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 1 |
| DC voltage range | 48 V |
| Power consumption (max) | 5 W |
| Weight & dimensions | |
| Width | 40 mm |
| Weight | 82 g |
| Height | 93 mm |
| Depth | 36.5 mm |
| Packaging content | |
| Mounting bracket(s) included | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 45 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Sustainability | |
| Sustainability compliance | Yes |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 1 |
