2.5Gbps uplink/10Gbps downlink, up to 20 km, 1x XG-PON port, 1x 2.5GbE RJ45 LAN port and 24V PoE in, 256 MB DDR, 32 MB NOR, 6W, UV-stabilized polycarbonate, black/white
Key Features
- (1) XG-PON port
- (1) 2.5GbE RJ45 LAN port and 24V PoE in
Description
An optical network unit that can deliver 2.5Gbps uplink/10Gbps downlink speeds over distances up to 20 km.
Specifications
| Network |
|---|
| Ethernet LAN data rates |
100,1000,2500 Mbit/s |
| Ethernet interface type |
2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| Maximum data transfer rate |
10000 Mbit/s |
| Fiber optic connector |
SC/APC |
| Performance |
|---|
| Maximum transfer distance |
20000 m |
| Tx power (min) |
2 dBmW |
| Tx power (max) |
7 dBmW |
| Rx power (min) |
-9 dBmW |
| Rx power (max) |
-27 dBmW |
| Features |
|---|
| Reset button |
Yes |
| Housing material |
Polycarbonate (PC) |
| LED indicators |
Yes |
| Product colour |
Black, White |
| Internal |
No |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Fiber ports quantity |
1 |
| Fiber optic connector |
SC/APC |
| Power |
|---|
| Power consumption (max) |
6 W |
| Power over Ethernet (PoE) |
Yes |
| Input current |
3 A |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Weight & dimensions |
|---|
| Width |
100 mm |
| Depth |
100 mm |
| Weight |
220 g |
| Height |
27 mm |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-15 - 45 °C |
| Operating relative humidity (H-H) |
10 - 95% |
| Technical details |
|---|
| Housing material |
Polycarbonate (PC) |
| Maximum transfer distance |
20000 m |
| Tx power (min) |
2 dBmW |
| Tx power (max) |
7 dBmW |
| Rx power (min) |
-9 dBmW |
| Rx power (max) |
-27 dBmW |
| Internal |
No |
| Sustainability compliance |
Yes |
| Compliance certificates |
CE, Federal Communications Commission (FCC), UKCA |
| Indication |
|---|
| LED indicators |
Yes |
| Design |
|---|
| Housing material |
Polycarbonate (PC) |
| LED indicators |
Yes |
| Product colour |
Black, White |
| Internal |
No |
| Management features |
|---|
| Reset button |
Yes |
| Colour |
|---|
| Product colour |
Black, White |
| Certificates |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC), UKCA |
