Enterprise Access Hub, 10x 10/100/1000 Base-T, AC/DC, internal, 240W, 8x PoE (Pins 1, 2+; 3, 6-), 379 x 355 x 105 mm
Key Features
- (8) Lock terminals (12V or Dry)
- (8+8) Inputs for request-to-exit devices and door position sensors
- (8) PoE ports for Access Readers
- (4) AUX terminals for chimes, sirens, or door openers
- (1) Battery backup input (32–48V)
Description
Enterprise-grade access hub with entry and exit control to eight doors and battery backup support.
Specifications
| Technical details |
|---|
| Maximum number of doors |
8 door(s) |
| Case design |
Cabinet |
| Interface |
Ethernet |
| Sustainability compliance |
Yes |
| Compliance certificates |
CE, Federal Communications Commission (FCC) |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
10 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
|---|
| Width |
355 mm |
| Weight |
9.1 kg |
| Height |
105 mm |
| Depth |
379 mm |
