Description
48 Gigabit PoE+ Ports, 4 SFP, 370W, 24 Gbps, 125W, 6 kV, 2 kg
Key Features
- 10-Port gigabit Layer 2 managed PoE switch, 2 SFP uplink
- Enterprise-class Quality Ensures High Performance
- IP Camera Recognition, Unique Value for CCTV Network
- Multiple Security Policies Protect Your Network
- Lifetime management on Ruijie Cloud at anytime anywhere
Description
Specifications
| Management features | |
|---|---|
| Switch type | Managed |
| Switch layer | L2 |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 4 |
| Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1s, IEEE 802.1w |
| VLAN support | Yes |
| Number of VLANs | 4094 |
| Flow control support | Yes |
| 10G support | No |
| Virtual LAN features | Voice VLAN |
| IGMP snooping | Yes |
| Data transmission | |
| Jumbo frames | 9216 |
| MAC address table | 8000 entries |
| Switching capacity | 56 Gbit/s |
| Jumbo frames support | Yes |
| Forwarding rate | 14.88 Mpps |
| Number of VLANs | 4094 |
| Security | |
| Security algorithms | HTTPS |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Design | |
| Product colour | Black |
| Stackable | Yes |
| Rack mounting | Yes |
| Performance | |
| Mean time between failures (MTBF) | 200000 h |
| Stackable | Yes |
| Power | |
| AC input voltage | 100 - 240 V |
| Power source | AC |
| Power over Ethernet (PoE) | |
| Power over Ethernet plus (PoE+) ports quantity | 48 |
| Total Power over Ethernet (PoE) budget | 370 W |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Virtual LAN features | |
| VLAN support | Yes |
| Number of VLANs | 4094 |
| Virtual LAN features | Voice VLAN |
| Weight & dimensions | |
| Width | 300 mm |
| Depth | 220 mm |
| Height | 43.6 mm |
| Packaging data | |
| Package weight | 2 kg |
| Technical details | |
| Product colour | Black |
| Stackable | Yes |
| Mean time between failures (MTBF) | 200000 h |
| Rack mounting | Yes |
| Compliance certificates | CE, RoHS |
| Certificates | |
| Compliance certificates | CE, RoHS |
