Description
802.11ax (Wi-Fi 6), 2976Mbps, 512MB, 100V~240V AC，50/60Hz
Key Features
- A professional and high performance Wi-Fi 6 business router
- Easy to set up the whole network with all-in-one machine
- Press button, Reyee Mesh networking done
- Integrated rich enterprise-grade features for business scenarios
- Securely monitoring the NVR/IPC/internal server anytime from anywhere
Description
Specifications
| Ethernet LAN features | |
|---|---|
| Ethernet WAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| DSL features | |
| DSL WAN | No |
| Mobile network | |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
| Network | |
| Network address translation (NAT) | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Static route | Yes |
| Load balancing system | Yes |
| Dynamic DNS (DDNS) | Yes |
| Management features | |
| Universal Plug and Play (UPnP) | Yes |
| MU-MIMO technology | Yes |
| MIMO | Yes |
| Number of data streams | 2x2 |
| Performance | |
| Built-in processor | Yes |
| WAN connection | |
| Ethernet WAN | Yes |
| DSL WAN | No |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
| WAN connection type | RJ-45 |
| Wireless LAN features | |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| WLAN data transfer rate (max) | 2976 Mbit/s |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (first band) | 574 Mbit/s |
| WLAN data transfer rate (second band) | 2402 Mbit/s |
| Wi-Fi standards | 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax) |
| Ports & interfaces | |
| USB port | Yes |
| Ethernet LAN (RJ-45) ports | 5 |
| Security | |
| Security algorithms | IPSec |
| Network address translation (NAT) | Yes |
| Firewall | Yes |
| DoS attack prevention | Yes |
| Access Control List (ACL) | Yes |
| Protocols | |
| Universal Plug and Play (UPnP) | Yes |
| DHCP client | Yes |
| Design | |
| Product type | Tabletop router |
| Product colour | Black, Grey |
| Certificates | |
| Compliance certificates | CE, RoHS |
| Antenna | |
| Antenna design | External |
| Antennas quantity | 5 |
| Antenna gain level (max) | 5 dBi |
| Features | |
| Built-in processor | Yes |
| Power | |
| Power source type | AC |
| Power consumption (typical) | 20 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width | 283 mm |
| Weight | 2 kg |
| Height | 46 mm |
| Depth | 172 mm |
| Technical details | |
| Compliance certificates | CE, RoHS |
