Description
8-Port Gigabit Smart Cloud Managed Non-PoE Switch
ES200 adopts a light-weighted Cloud management design, providing faster response to support richer features.
Automatic Loop Prevention Ensures Service Continuity
Network stays connected when network loop happens.
Cloud, Make Your Business Easy
- SON, zero touch provisioning to Cloud
- Configure VLANs on Ruijie Cloud APP
- Monitor switch statistics at anytime anywhere
- Easy maintainance, save onsite time and cost
Key Features
- 8-Port gigabit cloud managed non-PoE switch
- Cost-Effective Smart Cloud Managed Switches
- IP Camera Recognition, Unique Value for CCTV Network
- Automatic Loop Prevention Ensures Service Continuity
- Lifetime management on Ruijie Cloud at anytime anywhere
Description
Cost-Effective Smart Cloud Managed SwitchesES200 adopts a light-weighted Cloud management design, providing faster response to support richer features.
Automatic Loop Prevention Ensures Service Continuity
Network stays connected when network loop happens.
Cloud, Make Your Business Easy
- SON, zero touch provisioning to Cloud
- Configure VLANs on Ruijie Cloud APP
- Monitor switch statistics at anytime anywhere
- Easy maintainance, save onsite time and cost
Specifications
| Management features | |
|---|---|
| Reset button | Yes |
| Switch type | Managed |
| Web-based management | Yes |
| Switch layer | L2 |
| Cloud-managed | Yes |
| Network | |
| IGMP snooping | Yes |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| VLAN support | Yes |
| Number of VLANs | 16 |
| Flow control support | Yes |
| 10G support | No |
| Virtual LAN features | |
| VLAN support | Yes |
| Number of VLANs | 16 |
| Data transmission | |
| Number of VLANs | 16 |
| Packet buffer memory | 1.5 MB |
| MAC address table | 4000 entries |
| Switching capacity | 16 Gbit/s |
| Forwarding rate | 11.9 Mpps |
| Performance | |
| Packet buffer memory | 1.5 MB |
| Mean time between failures (MTBF) | 200000 h |
| Technical details | |
| Product colour | Grey |
| Mean time between failures (MTBF) | 200000 h |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Security | |
| IGMP snooping | Yes |
| DHCP features | DHCP client, DHCP snooping |
| Memory | |
| Packet buffer memory | 1.5 MB |
| Design | |
| Reset button | Yes |
| Product colour | Grey |
| Power | |
| Power consumption (typical) | 4 W |
| Input current | 1 A |
| DC input voltage | 5 V |
| Power source | DC |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | No |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating altitude | -500 - 5000 m |
| Weight & dimensions | |
| Width | 160 mm |
| Depth | 75 mm |
| Height | 24 mm |
| Packaging data | |
| Quick start guide | Yes |
| Package width | 197 mm |
| Package depth | 172 mm |
| Package height | 52 mm |
| Package weight | 490 g |
| Cables included | Power |
| Packaging content | |
| Quick start guide | Yes |
| Cables included | Power |
