Description
Handheld scanner, industry, 2D, Red/White/Blue LEDs, RS232, USB, IP64, USB cable
Handheld Scanners
With its comfortable, ergonomic design and dual-core processor with a 1D, 2D, and DPM barcode reader, the NVH220 Lophius is a reliable solution to streamline your barcode scanning operations. Equipped with advanced technology, AI function, and auto-learning technology, it effortlessly decodes various barcodes commonly found in industrial applications. The plug-and-play functionality makes configuration into demanding industrial environments a breeze.
High-Performance DPM Scanning
The NVH220 Lophius stands out with its exceptional proficiency in decoding DPM barcodes, including those made by laser part marking and dotting techniques. With dual-core parallel processing and improved computing power, the NVH220 significantly enhances image capture, recognition, and scanning speed, ensuring accurate and efficient decoding.
Highly Durable In Tough Environments
Designed with durability in mind, the NVH220 Lophius features a robust design that can withstand the toughest conditions. With its high-protection construction and IP64-sealed housing, this scanner ensures reliable performance, even in the face of dust, water, and repeated falls from heights of up to 1.8 meters.
Intelligent Learning
With the intelligent learning ability, the NVH220 Lophius enables automatic parameter adjustments based on previous scanning scenarios, ensuring optimal performance and adaptability. Leveraging three illumination colors and intelligent angle adjustments, the NVH220 Lophius automatically explores the options to find the optimal combination for scanning. Once identified, this scanner memorizes the last setting, ensuring efficiency in future code scans.
Advanced Illumination and AI Functionality
The NVH220 Lophius comes equipped with diverse lighting options, encompassing direct white and red illumination, along with diffuse blue ring lights. These advanced illumination capabilities empower the NVH220 Lophius to effortlessly scan even the most demanding barcodes across a diverse spectrum of materials (reflective surface), shapes (curved surfaces), backgrounds (low to high contrast), and barcode colors. With advanced AI capabilities, the NVH220 Lophius excels in barcode positioning and reconstruction, further enhancing its ability to tackle challenging barcodes.
Configure To Your Needs
With free configuration software Nset, the NVH220 Lophius can be easily configured to suit the needs of any application. Nset is specifically tailored for DPM and high-density scanners, providing users with enhanced flexibility and control over their devices.
Key Features
- 1D & 2D
- DPM
- LED aimer
- Nset
Description
NVH220 Lophius CordedHandheld Scanners
With its comfortable, ergonomic design and dual-core processor with a 1D, 2D, and DPM barcode reader, the NVH220 Lophius is a reliable solution to streamline your barcode scanning operations. Equipped with advanced technology, AI function, and auto-learning technology, it effortlessly decodes various barcodes commonly found in industrial applications. The plug-and-play functionality makes configuration into demanding industrial environments a breeze.
High-Performance DPM Scanning
The NVH220 Lophius stands out with its exceptional proficiency in decoding DPM barcodes, including those made by laser part marking and dotting techniques. With dual-core parallel processing and improved computing power, the NVH220 significantly enhances image capture, recognition, and scanning speed, ensuring accurate and efficient decoding.
Highly Durable In Tough Environments
Designed with durability in mind, the NVH220 Lophius features a robust design that can withstand the toughest conditions. With its high-protection construction and IP64-sealed housing, this scanner ensures reliable performance, even in the face of dust, water, and repeated falls from heights of up to 1.8 meters.
Intelligent Learning
With the intelligent learning ability, the NVH220 Lophius enables automatic parameter adjustments based on previous scanning scenarios, ensuring optimal performance and adaptability. Leveraging three illumination colors and intelligent angle adjustments, the NVH220 Lophius automatically explores the options to find the optimal combination for scanning. Once identified, this scanner memorizes the last setting, ensuring efficiency in future code scans.
Advanced Illumination and AI Functionality
The NVH220 Lophius comes equipped with diverse lighting options, encompassing direct white and red illumination, along with diffuse blue ring lights. These advanced illumination capabilities empower the NVH220 Lophius to effortlessly scan even the most demanding barcodes across a diverse spectrum of materials (reflective surface), shapes (curved surfaces), backgrounds (low to high contrast), and barcode colors. With advanced AI capabilities, the NVH220 Lophius excels in barcode positioning and reconstruction, further enhancing its ability to tackle challenging barcodes.
Configure To Your Needs
With free configuration software Nset, the NVH220 Lophius can be easily configured to suit the needs of any application. Nset is specifically tailored for DPM and high-density scanners, providing users with enhanced flexibility and control over their devices.
Specifications
| Scanning | |
|---|---|
| Type | Handheld bar code reader |
| Linear (1D) barcodes supported | AIM-128, Codabar, Code 11, Code 128, Code 39, Code 93, Deutsche12, Deutsche14, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), ISBN, ISSN, ITF-14, ITF-6, Industrial 2 of 5, Interleaved 2 of 5, MSI-Plessey, Matrix 2 of 5, Plessey, Standard 2 of 5, UPC-A, UPC-E |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, Micro QR Code, PDF417, QR Code |
| Yaw reading angle | -50 - 50° |
| Wavelength | 532 nm |
| Sensor type | CMOS |
| Scanner type | 1D/2D |
| Pitch reading angle | -50 - 50° |
| Maximum scan width | 21 cm |
| Optical sensor resolution (W x H) | 1280 x 960 pixels |
| Trigger mode | Manual |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Cable length | 1.8 m |
| Standard interfaces | USB |
| Performance | |
| Protection features | Electrostatic Discharge (ESD) protection |
| International Protection (IP) code | IP64 |
| Product colour | Black, Green |
| Certification | FCC, CE, ROHS, IEC63471 |
| Print contrast | 20% |
| Design | |
| Type | Handheld bar code reader |
| Protection features | Electrostatic Discharge (ESD) protection |
| International Protection (IP) code | IP64 |
| Product colour | Black, Green |
| Certification | FCC, CE, ROHS, IEC63471 |
| Power | |
| Power consumption | 475 mA |
| Power source type | AC |
| Input voltage | 5 V |
| Weight & dimensions | |
| Width | 67 mm |
| Depth | 86 mm |
| Height | 170 mm |
| Weight | 245 g |
| Technical details | |
| Type | Handheld bar code reader |
| Protection features | Electrostatic Discharge (ESD) protection |
| International Protection (IP) code | IP64 |
| Product colour | Black, Green |
| Certification | FCC, CE, ROHS, IEC63471 |
| Packaging data | |
| Cables included | RS-232, USB |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | -20 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Packaging content | |
| Cables included | RS-232, USB |
