Description
Dual-core ARM Cortex-A53 at 1 GHz, 512 MB DDR3L, GbE RJ45, 10W, IPX6, UV stabilized polycarbonate, white
Key Features
- Max. link range: Wave AP: 1.3 km / Wave AP Micro: 0.9 km
- Max. throughput: 2 Gbps (1 Gbps duplex)
- 5 GHz weatherproof backup radio (Max. throughput: 800 Mbps)
- (1) GbE RJ45 port
- Integrated Bluetooth
Description
Lightweight, compact 60 GHz PtMP station powered by Wave Technology.Specifications
| Data transmission | |
|---|---|
| Maximum data transfer rate | 800 Mbit/s |
| Maximum transfer distance | 1300 m |
| Antenna | |
| Antenna gain level (max) | 27.7 dBi |
| Antenna design | Internal |
| Wireless LAN features | |
| Outdoor range | 0.9 - 1.3 km |
| Frequency band | 5.18 - 5.875 GHz |
| Modulation | 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, QPSK |
| Antenna gain level (max) | 27.7 dBi |
| Wi-Fi | Yes |
| Wi-Fi band | Single-band (5 GHz) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10,100,1000,2000 Mbit/s |
| Ethernet LAN interface type | Multi-Gigabit Ethernet |
| Outdoor range | 0.9 - 1.3 km |
| Frequency band | 5.18 - 5.875 GHz |
| Ports & interfaces | |
| Ethernet LAN | Yes |
| Connectivity technology | Wired & Wireless |
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
| Security algorithms | SNMP, WPA2-PSK |
| Features | |
| Product type | Network bridge |
| Material | Polycarbonate (PC) |
| Product colour | White |
| Reset button | Yes |
| Processor family | ARM Cortex |
| Processor model | Cortex-A53 |
| RAM type | DDR3L |
| Processor frequency | 1000 MHz |
| Network Time Protocol (NTP) client | Yes |
| International Protection (IP) code | IPX6 |
| Power LED | Yes |
| LED indicators | LAN, Link, Power, Status |
| Internal memory | 512 MB |
| Processor manufacturer | ARM |
| Mounting type | Pole |
| Power | |
| Power consumption (max) | 10 W |
| Power source type | PoE |
| DC input voltage | 44 - 54 V |
| Power over Ethernet (PoE) | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -40 - 140 °F |
| Management features | |
| LED indicators | LAN, Link, Power, Status |
| Certificates | |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Technical details | |
| Material | Polycarbonate (PC) |
| Product colour | White |
| Operating temperature (T-T) | -40 - 140 °F |
| Internal memory | 512 MB |
| Quantity per pack | 1 pc(s) |
| Compliance certificates | CE, Federal Communications Commission (FCC), Industry Canada (IC) |
| Weight & dimensions | |
| Weight | 347 g |
| Width | 152.1 mm |
| Depth | 55.8 mm |
| Height | 152.1 mm |
| Processor | |
| Processor family | ARM Cortex |
| Processor model | Cortex-A53 |
| Processor frequency | 1000 MHz |
| Processor manufacturer | ARM |
| Memory | |
| RAM type | DDR3L |
| Indication | |
| Power LED | Yes |
| Packaging content | |
| Quick installation guide | Yes |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
