Description
1/2.7", CMOS, 2.8–13 mm, 5MP, 2048 MB RAM, 8192 MB Flash, 2592x1944px, WDR, 480 g
A camera you can count on
With electronic image stabilization, AXIS P1387 ensures stable images despite vibration. Scene profiles can be automatically optimized to suit specific scenarios. And thanks to shock detection and a tampering alarm, you’ll be informed if there’s any attempts to interfere with the camera. Barrel distortion correction delivers great image quality, even at the edges of the image. Plus, corridor format ensures the video is perfectly adapted to monitored corridors or tunnels. With support for PoE and redundant DC power, this box camera offers flexible installation. Furthermore, it’s designed to fit into outdoor housing.
More light or less
With an exchangeable lens and i-CS support, you can easily change the lens, making this camera ideal for various surveillance situations. Use our lens calculator to select a lens that meets your specific needs. This box camera offers excellent image quality in 5 MP. With Lightfinder 2.0, and Forensic WDR it delivers true colors and great detail in challenging light or near darkness. In addition, P-Iris ensures images with better contrast, clarity, resolution, and depth of field.
Secure and powerful
AXIS P1387 offers Axis Edge Vault, a hardware-based cybersecurity platform that safeguards the device and protects sensitive information from unauthorized access. Built on an Axis system-on-chip, it includes a deep learning processing unit (DLPU) so you can run advanced features and powerful analytics on the edge. For instance, AXIS Object Analytics can detect and classify different types of objects. This DLPU also ensures improved processing and storage capabilities so you can collect and analyze even more data than before. Plus, it delivers valuable metadata facilitating fast, easy, and efficient forensic search capabilities in live or recorded video.
Key Features
- Excellent image quality in 5 MP
- Lightfinder 2.0 and Forensic WDR
- Exchangeable lens
- Analytics with deep learning
- Built-in cybersecurity with Axis Edge Vault
Description
This box camera delivers excellent 5 MP image quality. Ideal for various surveillance situations, it offers an exchangeable lens so you can change the lens to suit your needs. Plus, it’s designed for use outdoors in housing.A camera you can count on
With electronic image stabilization, AXIS P1387 ensures stable images despite vibration. Scene profiles can be automatically optimized to suit specific scenarios. And thanks to shock detection and a tampering alarm, you’ll be informed if there’s any attempts to interfere with the camera. Barrel distortion correction delivers great image quality, even at the edges of the image. Plus, corridor format ensures the video is perfectly adapted to monitored corridors or tunnels. With support for PoE and redundant DC power, this box camera offers flexible installation. Furthermore, it’s designed to fit into outdoor housing.
More light or less
With an exchangeable lens and i-CS support, you can easily change the lens, making this camera ideal for various surveillance situations. Use our lens calculator to select a lens that meets your specific needs. This box camera offers excellent image quality in 5 MP. With Lightfinder 2.0, and Forensic WDR it delivers true colors and great detail in challenging light or near darkness. In addition, P-Iris ensures images with better contrast, clarity, resolution, and depth of field.
Secure and powerful
AXIS P1387 offers Axis Edge Vault, a hardware-based cybersecurity platform that safeguards the device and protects sensitive information from unauthorized access. Built on an Axis system-on-chip, it includes a deep learning processing unit (DLPU) so you can run advanced features and powerful analytics on the edge. For instance, AXIS Object Analytics can detect and classify different types of objects. This DLPU also ensures improved processing and storage capabilities so you can collect and analyze even more data than before. Plus, it delivers valuable metadata facilitating fast, easy, and efficient forensic search capabilities in live or recorded video.
Specifications
| Performance | |
|---|---|
| Infrared (IR) cut-off filter | Yes |
| Languages support | Multi |
| Processor model | ARTPEC-8 |
| Type | IP security camera |
| Connectivity technology | Wired |
| PTZ control | Yes |
| Placement supported | Indoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Built-in processor | Yes |
| Dynamic range | 120 dB |
| Design | |
| Form factor | Box |
| Product colour | White |
| Mounting type | Wall |
| Housing material | Aluminium |
| Camera | |
| Minimum illumination | 0.008 lx |
| Camera shutter speed | 1/66500 - 2 s |
| Camera pixel size | 2 µm |
| Lens viewing angle, horizontal | 24 - 112° |
| Lens viewing angle, vertical | 18 - 80° |
| Image sensor | |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
| Lens system | |
| Number of lenses | 1 |
| Auto focus | Yes |
| Recognize distance (wide) | 11.2 m |
| Recognize distance (tele) | 48.8 m |
| Observe distance (wide) | 22.3 m |
| Observe distance (tele) | 96.9 m |
| Identify distance (wide) | 5.6 m |
| Identify distance (tele) | 24.4 m |
| Detect distance (wide) | 56.2 m |
| Detect distance (tele) | 244.2 m |
| Minimum aperture number | 1.4 |
| Focal length range | 2.8 - 13 mm |
| Video | |
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Sharpness |
| Privacy masking | Yes |
| Flip & mirror | Yes |
| Image stabilizer | Yes |
| Gain control type | Auto |
| Bit rate control | Variable Bit Rate (VBR) |
| Noise reduction technology | 2D noise reduction, 3D noise reduction |
| Video compression formats | H.264, H.265, M-JPEG, MPEG4 |
| Maximum resolution | 2592 x 1944 pixels |
| Supported graphics resolutions | 160 x 120, 160 x 90, 2592 x 1944 |
| Frame rate | 60 fps |
| Video streaming | Yes |
| Total megapixels | 5 MP |
| Audio | |
| Signal-to-Noise Ratio (SNR) | 55 dB |
| Built-in microphone | Yes |
| Audio system | 2-way |
| Audio formats supported | G.711, G.726, LPCM, OPUS |
| Audio detection | Yes |
| Network | |
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Networking standards | IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Quality of Service (QoS) support | Yes |
| Streaming method | Multicast |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Storage | |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Internal memory | 2048 MB |
| Flash memory | 8192 MB |
| Ports & interfaces | |
| Terminal block port | Yes |
| RS-485 ports | 1 |
| RS-422 ports | 1 |
| Microphone in | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Connectivity technology | Wired |
| Security | |
| Intelligent Video Surveillance (IVS) system features | Face detection, Human detection, Line crossing detection, Scene change, Vehicle detection |
| Video motion detection | Yes |
| Active tampering alarm | Yes |
| Alarm input channels | 2 |
| Alarm output channels | 2 |
| Power | |
| Power source type | DC, PoE |
| Power consumption (max) | 10.57 W |
| Power consumption (Power over Ethernet (PoE)) | 11.73 W |
| Power consumption (typical) | 4.26 W |
| DC-in jack | Yes |
| DC output voltage | 10, 28 |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 55 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width | 80 mm |
| Depth | 225 mm |
| Height | 63.5 mm |
| Weight | 480 g |
| Weight (with stand) | 775 g |
| Sustainability | |
| Compliance certificates | CE, EAC, KC, RCM, REACH, RoHS, UKCA, UL, VCCI, cUL |
| Packaging content | |
| Number of cameras | 1 |
| Terminal block included | Yes |
| Mounting kit | Yes |
| Manual | Yes |
| Technical details | |
| Doesn't contain | BFR |
| Compliance certificates | CE, EAC, KC, RCM, REACH, RoHS, UKCA, UL, VCCI, cUL |
| Other features | |
| Video compression formats | H.264, H.265, M-JPEG, MPEG4 |
| Doesn't contain | BFR |
