32" Full HD Professional Digital Signage 24/7 display featuring Android OS and FailOver
Reasons To Buy
Android OS
Thanks to Android OS, you can easily customize the display to your needs by installing applications directly to it.
iiSignage²
iiSignage² is our digital signage content management platform to easily show and control your content and to manage your displays in a secure way. The Content Management System (CMS) gives you total control of your messaging and advertising remotely and safely.
Signal FailOver
FailOver is a feature which automatically detects input sources. When there is no signal on the default input it will automatically switch to the next available input. FailOver allows customers to prioritize a number of inputs (incl. Browser, Media Player and Custom) and ensures your content is always actively displayed, assuring active content at all times.
Media player
Play your favourite music and show your most beautiful videos, photos and images directly on screen from a flash drive or the internal memory with the built-in media player.
Full HD
With true 1920 x 1080p resolution your monitor is ready to display high definition images. This means you can accommodate more information on your screen; e.g. 60% more in comparison to a 1280 x 1024 monitor.
Description
Choose non-stop high performance and reliability with the ideal all-in-one signage solution for mission critical environments. The LH3275HS from iiyama can be operated in landscape or portrait orientation in continual around the clock environments, 24/7 without any interruption. Its versatility can be adapted to your industry’s display needs. On-board Android 11 OS means you can easily customize the display to your needs and install applications directly to it. The on-board iiSignage² (Content Management System) gives you total control of your messaging and advertising remotely and safely. The FailOver feature ensures your content is always actively displayed through your choice of inputs. The built-in (and removable) WiFi module means this series is ready for remote content delivery using your network. With the EShare app you bring effortless ideation and efficient collaboration in your enterprise or school. You can start sharing wirelessly easier than ever before.
Specifications
| Display |
|---|
| Panel type |
IPS |
| Display number of colours |
16.7 million colours |
| Touchscreen |
No |
| Active display area (W x H) |
698.4 x 392.85 mm |
| Display technology |
LCD |
| Display diagonal |
80 cm (31.5") |
| Display resolution |
1920 x 1080 pixels |
| Display brightness |
500 cd/m² |
| HD type |
Full HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.364 x 0.364 mm |
| Display diagonal (metric) |
80 cm |
| Native aspect ratio |
16:9 |
| Horizontal scan range |
28 - 160 kHz |
| Anti-glare screen |
Yes |
| Maximum frame rate |
60 fps |
| Native refresh rate |
60 Hz |
| Haze rate |
25% |
| RGB colour space |
sRGB |
| Ports & interfaces |
|---|
| DisplayPort version |
1.2 |
| USB port |
Yes |
| HDMI version |
2.0 |
| RS-232C |
Yes |
| Wi-Fi standards |
Wi-Fi 5 (802.11ac) |
| Wi-Fi |
Yes |
| PC Audio in |
Yes |
| DisplayPorts quantity |
1 |
| Ethernet LAN |
Yes |
| HDMI ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
1 |
| USB version |
2.0 |
| USB ports quantity |
2 |
| Audio Return Channel (ARC) |
Yes |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Placement supported |
Indoor |
| Orientation |
Horizontal/Vertical |
| Housing material |
Metal |
| Bezel width (top) |
1.19 cm |
| Bezel width (side) |
1.19 cm |
| Bezel width (bottom) |
1.19 cm |
| Product colour |
Black |
| Panel mounting interface |
200 x 200 mm |
| Certification |
CB, CE, TÜV-Bauart, EAC, ErP, WEEE, REACH |
| VESA mounting |
Yes |
| Anti-glare screen |
Yes |
| Bezel colour |
Black |
| Performance |
|---|
| Purpose |
Universal |
| Operating hours (hours/days) |
24/7 |
| Mean time between failures (MTBF) |
44000 h |
| On Screen Display (OSD) languages |
Czech, German, Dutch, English, Spanish, French, Italian, Japanese, Polish, Russian |
| On Screen Display (OSD) |
Yes |
| Number of OSD languages |
11 |
| HDCP |
Yes |
| HDCP version |
2.2 |
| Wi-Fi |
Yes |
| Power |
|---|
| Power consumption (off) |
0.3 W |
| Power consumption (typical) |
46 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
G |
| Energy consumption (SDR) per 1000 hours |
46 kWh |
| Computer system |
|---|
| Processor cores |
4 |
| Processor family |
ARM Cortex |
| Operating system installed |
Android 11 |
| Internal memory |
4 GB |
| Internal storage capacity |
32 GB |
| Processor manufacturer |
ARM |
| Built-in processor |
Yes |
| On-board graphics card model |
ARM Mali-G52 |
| Processor architecture |
ARM Cortex-A73 |
| Weight & dimensions |
|---|
| Display width |
725.5 mm |
| Display depth |
54 mm |
| Display height |
421.8 mm |
| Display weight |
5.2 kg |
| Packaging data |
|---|
| Package width |
824 mm |
| Package depth |
824 mm |
| Package height |
554 mm |
| Package weight |
7.3 kg |
| Quick start guide |
Yes |
| Batteries included |
Yes |
| Remote control included |
Yes |
| Cables included |
AC, HDMI, RS-232 |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Batteries included |
Yes |
| Remote control included |
Yes |
| Cables included |
AC, HDMI, RS-232 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Certificates |
|---|
| Certification |
CB, CE, TÜV-Bauart, EAC, ErP, WEEE, REACH |
| Technical details |
|---|
| VESA mounting |
Yes |
| Panel type |
IPS |
| DisplayPort version |
1.2 |
| Compliance certificates |
RoHS |
| Thin Client |
|---|
| Processor family |
ARM Cortex |
| Operating system installed |
Android 11 |
| Internal memory |
4 GB |
| Internal storage capacity |
32 GB |
| Logistics data |
|---|
| Harmonized System (HS) code |
85285210 |
| Features |
|---|
| Harmonized System (HS) code |
85285210 |
| Other features |
|---|
| Panel type |
IPS |
| DisplayPort version |
1.2 |
| Housing material |
Metal |
| Wi-Fi standards |
Wi-Fi 5 (802.11ac) |
| Wi-Fi |
Yes |
| Mean time between failures (MTBF) |
44000 h |
| Display technology |
LCD |
| Bezel width (top) |
1.19 cm |
| Bezel width (side) |
1.19 cm |
| Bezel width (bottom) |
1.19 cm |
| Quick start guide |
Yes |
| Energy efficiency scale |
A to G |
