Description
Active powered Subwoofer 8" 50W + 2x25W 2.1
Ideal for meeting rooms, hotels and auditoriums.
It have line input and loop out for active sattelite speakers.
Subwoofer can also be used together with passive sattelite speakers using the internal power amplifier for sattelige speakers on 2 x 25W
• For rooms up to 200m2
• Power effect for subwoofer: 50 Watts
• Power effect for passive ceiling speakers:
(VLSPMTC60WT) 2x25Watts
• Inputs: 100V, Balanced in and RCA line in
• Bluetooth input for speaker out only (not supported for line-out)
• Outputs: RCA line out and Speaker out 2x 25W
• Line out for active speakers (VLSP60/65/61/70)
• Frequency range: 80Hz-20kHz
• Impedance: 8 Ohm
Key Features
- Active powered Subwoofer 8" 50W
- 2x25W speaker output + line- out
- Silent on/off via automatic ECO mode after 90 seconds (less than 0,5 Watt)
- Audio inputs: 2xRCA + 100V + Balanced input + Bluetooth for (speaker out only)
- Switchable stereo / mono output
Description
Vivolink Active Subwoofer is a perfect match to all Vivolink speakers. It is designed to be mounted over ceiling or under funitureIdeal for meeting rooms, hotels and auditoriums.
It have line input and loop out for active sattelite speakers.
Subwoofer can also be used together with passive sattelite speakers using the internal power amplifier for sattelige speakers on 2 x 25W
• For rooms up to 200m2
• Power effect for subwoofer: 50 Watts
• Power effect for passive ceiling speakers:
(VLSPMTC60WT) 2x25Watts
• Inputs: 100V, Balanced in and RCA line in
• Bluetooth input for speaker out only (not supported for line-out)
• Outputs: RCA line out and Speaker out 2x 25W
• Line out for active speakers (VLSP60/65/61/70)
• Frequency range: 80Hz-20kHz
• Impedance: 8 Ohm
Specifications
| Loudspeakers | |
|---|---|
| Speaker type | 2-way |
| Speaker placement | Wall-mountable |
| Number of drivers | 2 |
| Tweeter diameter (imperial) | 2.54 cm (1") |
| Woofer diameter (imperial) | 13.3 cm (5.25") |
| Recommended usage | Universal |
| Audio output channels | 2.0 channels |
| Number of speakers | 2 |
| Audio | |
| Speakers RMS power | 30 W |
| Peak Music Power Output (PMPO) | 300 W |
| Frequency range | 45 - 20000 Hz |
| Impedance | 4 Ω |
| Sensitivity | 88 dB |
| RMS rated power | 60 W |
| Performance | |
| Housing material | Plastic |
| Volume control | Rotary |
| Certification | CE |
| Recommended usage | Universal |
| Number of speakers | 2 |
| Technical details | |
| Speaker type | 2-way |
| Volume control | Rotary |
| Certification | CE |
| Front speaker sensitivity | 88 dB |
| Front speaker impedance | 4 Ω |
| Front speaker frequency range | 45 - 20000 Hz |
| Power source | AC |
| Housing colour | White |
| Design | |
| Housing material | Plastic |
| Certification | CE |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Connector(s) | RCA, Minijack, Phoenix |
| Cord length | 10 m |
| 6.35 mm (1⁄4-inch) input | 1 |
| Audio RCA inputs | 1 |
| Power | |
| Power consumption (typical) | 75 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 230 - 240 V |
| Power source type | AC |
| Current | 1 A |
| Material | |
| Housing material | Plastic |
| Weight & dimensions | |
| Width | 178 mm |
| Depth | 162 mm |
| Height | 240 mm |
| Weight | 6.26 kg |
| Cord length | 10 m |
| Speaker weight | 6.36 g |
| Package width | 440 mm |
| Package depth | 210 mm |
| Package height | 265 mm |
| Package weight | 6.75 kg |
| Packaging data | |
| Package width | 440 mm |
| Package depth | 210 mm |
| Package height | 265 mm |
| Package weight | 6.75 kg |
| Packaging content | |
| Cables included | AC |
| Features | |
| Front speaker sensitivity | 88 dB |
| Front speaker impedance | 4 Ω |
| Front speaker frequency range | 45 - 20000 Hz |
| Housing colour | White |
| Other features | |
| Front speaker sensitivity | 88 dB |
| Front speaker impedance | 4 Ω |
| Front speaker frequency range | 45 - 20000 Hz |
| Power source | AC |
| Housing colour | White |
| Speaker weight | 6.36 g |
| Audio output channels | 2.0 channels |
