Description
800 MHz, RouterOS v7, 256 MB, 128 MB, 12-28 V, DC, 802.11b/g/n/ax, Wi-Fi 6, USB type A,
It features a modern dual-core ARM CPU, Gigabit Ethernet and 2.5 Gigabit SFP for fiber connectivity, a USB port, and a free miniPCIe slot that allows further customization. You could, for example, add an LTE modem for a mobile internet backup – we’ve added a NanoSIM slot on the NetMetal! But there are other options, like adding a gateway for LoRa IoT setups, such as our R11e-LR8!
A powerful dual-band, dual-chain Wi-Fi 6 radio offers increased speed, stability, security, roaming, power management, and other features, compared to the previous wireless protocols. Two RP-SMA connectors allow adding an antenna of your choice for distances up to 30 kilometers.*. If necessary, you can adapt the NetMetal ax for lower range use with such antennas as our HGO-antenna-OUT screw-on omni antenna unit. It provides 3.3 dBi gain for the 2.4 GHz band and 5.5-7.1 dBi gain for the 5 GHz band.
If you’ve read this far, here’s a little bonus feature: we’ve kept the good old beeper for various alarms or creative outputs.
*It’s important to note that while longer links are feasible, their reliability may vary. Additionally, the distance achievable greatly depends on the antenna selected for use.
Description
Meet one of your most versatile companions: the NetMetal ax – a powerful long-range outdoor access point that thrives in any environment. Designed for extra durability, it can be installed almost anywhere with ease – you can open and close the case with one hand. The rated IP66 protection will keep the device safe from dust and powerful water jets - in damp attics and elevator shafts, bustling docks, or coastal tower structures. No terrain is too rough for the NetMetal ax – the Mars rover of networking!It features a modern dual-core ARM CPU, Gigabit Ethernet and 2.5 Gigabit SFP for fiber connectivity, a USB port, and a free miniPCIe slot that allows further customization. You could, for example, add an LTE modem for a mobile internet backup – we’ve added a NanoSIM slot on the NetMetal! But there are other options, like adding a gateway for LoRa IoT setups, such as our R11e-LR8!
A powerful dual-band, dual-chain Wi-Fi 6 radio offers increased speed, stability, security, roaming, power management, and other features, compared to the previous wireless protocols. Two RP-SMA connectors allow adding an antenna of your choice for distances up to 30 kilometers.*. If necessary, you can adapt the NetMetal ax for lower range use with such antennas as our HGO-antenna-OUT screw-on omni antenna unit. It provides 3.3 dBi gain for the 2.4 GHz band and 5.5-7.1 dBi gain for the 5 GHz band.
If you’ve read this far, here’s a little bonus feature: we’ve kept the good old beeper for various alarms or creative outputs.
*It’s important to note that while longer links are feasible, their reliability may vary. Additionally, the distance achievable greatly depends on the antenna selected for use.
Specifications
| Data transmission | |
|---|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Performance | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Reset button | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Certification | CE, FCC, IC, EAC, ROHS |
| Chipset | QCN-6102, IPQ-5010 |
| Operating system installed | RouterOS |
| Internal memory | 128 MB |
| Flash memory | 256 MB |
| Compatible operating systems | RouterOS v7 |
| Built-in processor | Yes |
| Processor frequency | 800 MHz |
| Wireless LAN features | |
| Wireless standard | 802.11a/n/ac/ax |
| Ports & interfaces | |
| I/O ports | SFP |
| USB connector type | USB Type-A |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Yes |
| Memory | |
| Internal memory | 128 MB |
| Flash memory | 256 MB |
| Features | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Operating system installed | RouterOS |
| Internal memory | 128 MB |
| Flash memory | 256 MB |
| Compatible operating systems | RouterOS v7 |
| Built-in processor | Yes |
| Processor frequency | 800 MHz |
| Power | |
| Power consumption (max) | 25 W |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) type supported | Passive PoE |
| Design | |
| Placement | Wall |
| Product colour | Black |
| Reset button | Yes |
| Certification | CE, FCC, IC, EAC, ROHS |
| Technical details | |
| Reset button | Yes |
| Processor | |
| Built-in processor | Yes |
| Certificates | |
| Certification | CE, FCC, IC, EAC, ROHS |
| Mobile network | |
| SIM card slot | Yes |
| SIM card type | NanoSIM |
| Other features | |
| I/O ports | SFP |
| Wireless standard | 802.11a/n/ac/ax |
| System requirements | |
| Compatible operating systems | RouterOS v7 |
