Description
Gigabit Ethernet PoE+ Injector Hub, 802.3bt 8- Port, PoE Power Budget 250W
- 8-Channel Power Distribution: The DN-95118 supports up to 8 channels, providing a versatile solution for multiple device installations.
- IEEE802.3bt Compliance: Ensures adherence to the latest PoE standards, guaranteeing compatibility with a wide range of devices.
- Compact and Cost-Effective: The space-saving design and affordability of the DN-95118 make it an efficient choice for businesses of all sizes.
- Eliminates External Power Supply: Say goodbye to the hassle of external power supplies and AC/DC cabling, reducing installation complexity and costs.
- Remote Powering: Perfect for installations where device accessibility is a challenge, the DN-95118 offers remote power delivery over existing Ethernet infrastructure.
Introducing the DN-95118 8-Channel Mid-Span Power over Ethernet (PoE) solution – a cutting-edge, compact, and cost-effective solution designed to revolutionize the way you power and connect your devices. Whether you're managing wireless LAN access points, IP security cameras, VoIP telephones, or other low port density installations, the DN-95118 is engineered to provide a seamless and efficient power solution. Compliance with the IEEE802.3bt standard ensures that the DN-95118 meets the latest industry requirements for PoE technology, delivering power and data over a single Ethernet cable. This eliminates the need for an external power supply and the associated AC/DC power cabling, streamlining your infrastructure and reducing installation costs. One of the standout features of the DN-95118 is its ability to remotely power a variety of devices, making it an ideal choice for installations where accessibility is a challenge. By utilizing existing Ethernet infrastructure, this mid-span PoE solution offers a convenient and reliable power source without the complexities of additional wiring. The compact design of the DN-95118 ensures that it seamlessly integrates into your environment without occupying valuable space. Its affordability, combined with its safety and reliability features, makes it an attractive choice for businesses looking to optimize their power solutions without compromising on performance.
Key Features
- IEEE802.3af, IEEE802.3at, IEEE802.3bt-type4
- Up to 8 Channel
- Up to 90W of power on 4-pairs per channel
- PoE Budget 250W
- Supports 10/100/1000 Base-T applications
- LED indicators power input and PoE output indication
- Distance up to 100 meters
- Internal AC/DC converter - no need for external power brick
- Easy plug-and-play installation
- Interfaces: 8 x RJ-45 Connector for Data, 8 x RJ-45 Connector for PoE out + Data
- LED Indicators: Power, Channel LED
- Data Rate: 10/100/1000Mbps
- Standard: IEEE802.3af, IEEE802.3at, IEEE802.3bt-type4
- Power Method: 100-240VAC, 50/60Hz
- Output Voltage: 54VDC
- PoE Budget: 250W
- Max. PoE Wattage per Port 90W
- Output PoE Pin Assignment: Alternative A: V+ (RJ45 Pin3,6), V- (RJ45 Pin 1,2); Alternative B: V+ (RJ45 Pin4,5), V- (RJ45 Pin 7,8)
- Dimensions: 275 x 200 x 44 mm
- Operating Temperature: 0 to 40℃
- Storage Temperature: -10 to 70℃
- Operating Humidity: 5 to 95% Noncondensing
Description
Upgrade your power infrastructure with the DN-95118 8-Channel Mid-Span PoE solution – unlocking a new level of efficiency, reliability, and cost-effectiveness for your networked devices.- 8-Channel Power Distribution: The DN-95118 supports up to 8 channels, providing a versatile solution for multiple device installations.
- IEEE802.3bt Compliance: Ensures adherence to the latest PoE standards, guaranteeing compatibility with a wide range of devices.
- Compact and Cost-Effective: The space-saving design and affordability of the DN-95118 make it an efficient choice for businesses of all sizes.
- Eliminates External Power Supply: Say goodbye to the hassle of external power supplies and AC/DC cabling, reducing installation complexity and costs.
- Remote Powering: Perfect for installations where device accessibility is a challenge, the DN-95118 offers remote power delivery over existing Ethernet infrastructure.
Introducing the DN-95118 8-Channel Mid-Span Power over Ethernet (PoE) solution – a cutting-edge, compact, and cost-effective solution designed to revolutionize the way you power and connect your devices. Whether you're managing wireless LAN access points, IP security cameras, VoIP telephones, or other low port density installations, the DN-95118 is engineered to provide a seamless and efficient power solution. Compliance with the IEEE802.3bt standard ensures that the DN-95118 meets the latest industry requirements for PoE technology, delivering power and data over a single Ethernet cable. This eliminates the need for an external power supply and the associated AC/DC power cabling, streamlining your infrastructure and reducing installation costs. One of the standout features of the DN-95118 is its ability to remotely power a variety of devices, making it an ideal choice for installations where accessibility is a challenge. By utilizing existing Ethernet infrastructure, this mid-span PoE solution offers a convenient and reliable power source without the complexities of additional wiring. The compact design of the DN-95118 ensures that it seamlessly integrates into your environment without occupying valuable space. Its affordability, combined with its safety and reliability features, makes it an attractive choice for businesses looking to optimize their power solutions without compromising on performance.
Specifications
| Network | |
|---|---|
| Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Power over Ethernet (PoE) | Yes |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Power over Ethernet (PoE) voltage | 54 V |
| Features | |
| Plug and Play | Yes |
| Maximum operating distance | 100 m |
| Product colour | Grey |
| LED indicators | Yes |
| Number of fans | 1 fan(s) |
| Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 16 |
| RJ-45 input ports | 8 |
| RJ-45 output ports | 8 |
| Power | |
| Output power | 85 W |
| Total Power over Ethernet (PoE) budget | 250 W |
| Power over Ethernet (PoE) power per port | 90 W |
| Power over Ethernet (PoE) voltage | 54 V |
| Input voltage | 100 - 240 V |
| Input frequency | 50/60 Hz |
| Operational conditions | |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width | 275 mm |
| Depth | 200 mm |
| Height | 44 mm |
| Package weight | 2.69 kg |
| Package depth | 95 mm |
| Package width | 280 mm |
| Package height | 340 mm |
| Packaging content | |
| Power cord included | Yes |
| Quick installation guide | Yes |
| Number of products included | 1 pc(s) |
| Packaging content | 1 x PoE injector 6 x Screws 1 x QIG 1 x AC power cord 2 x Mounting brackets 4 x Rubber feet |
| Packaging data | |
| Package weight | 2.69 kg |
| Package depth | 95 mm |
| Package width | 280 mm |
| Package height | 340 mm |
| Technical details | |
| Number of products included | 1 pc(s) |
| Package width | 280 mm |
| Package height | 340 mm |
| Power over Ethernet (PoE) | Yes |
| Input voltage | 100 - 240 V |
| Input frequency | 50/60 Hz |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Indication | |
| LED indicators | Yes |
| Logistics data | |
| Master (outer) case width | 350 mm |
| Master (outer) case length | 300 mm |
| Master (outer) case height | 500 mm |
| Master (outer) case gross weight | 13.4 kg |
| Master (outer) case volume | 52500 cm³ |
| Products per master (outer) case | 5 pc(s) |
| Customs product code (TARIC) | 8517620000 |
