Description
800 VA, 480 W, 4.1 kg
The iPlug series is the ideal solution for household, and small home office systems. Its compact size and versatility - push-button operation, LED status panel and user-replaceable batteries - make iPlug easy to install within a domestic environment to protect systems from surges and blackouts. When mains power fails the load is powered by the inverter and built-in battery. PowerShield³ UPS monitoring and control software can be used for an orderly unattended shutdown of IT systems.
Key Features
- ECO LINE energy efficient product
- Compact, ergonomic design
- 5 sockets with battery backup
- 3 sockets with surge protection only
- Cold start capability to power up the UPS without mains power
- User replaceable batteries
- USB interface for remote monitoring
- Power cable included
- Protection from short-circuits
- Auto restart - when the mains returns after battery exhaustion
- GS/Nemko safety marking
- Available with French (2P+T), English, Schuko and Italian outlets
Description
Versatile, robust and contemporary design.The iPlug series is the ideal solution for household, and small home office systems. Its compact size and versatility - push-button operation, LED status panel and user-replaceable batteries - make iPlug easy to install within a domestic environment to protect systems from surges and blackouts. When mains power fails the load is powered by the inverter and built-in battery. PowerShield³ UPS monitoring and control software can be used for an orderly unattended shutdown of IT systems.
Specifications
| Power | |
|---|---|
| Output power | 480 W |
| Input operation voltage (min) | 220 V |
| Input operation voltage (max) | 240 V |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Output power capacity | 0.8 kVA |
| Performance | |
| Number of output phases | 1 |
| Number of input phases | 1 |
| LED indicators | Yes |
| Features | |
| Output frequency | 50/60 Hz |
| Number of output phases | 1 |
| Number of input phases | 1 |
| Output power | 480 W |
| Input operation voltage (min) | 220 V |
| Input operation voltage (max) | 240 V |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Output power capacity | 0.8 kVA |
| Input frequency | 50/60 Hz |
| Ports & interfaces | |
| USB port | Yes |
| AC outlets quantity | 6 AC outlet(s) |
| Power plug | C13 coupler |
| USB 2.0 ports quantity | 1 |
| Battery | |
| Number of batteries supported | 1 |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery recharge time | 8 h |
| Design | |
| Form factor | Compact |
| LED indicators | Yes |
| Product colour | Black |
| Certification | EMC 2014/30/UE IEC EN 62040-1 EMC IEC EN 62040-2 RoHS |
| Control type | Buttons |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Technical details | |
| Output frequency | 50/60 Hz |
| Weight & dimensions | |
| Weight | 4.1 kg |
| Width | 185 mm |
| Height | 99 mm |
| Depth | 313 mm |
| Packaging data | |
| Quick installation guide | Yes |
| Cables included | Input power cable |
| Certificates | |
| Certification | EMC 2014/30/UE IEC EN 62040-1 EMC IEC EN 62040-2 RoHS |
| Packaging content | |
| Quick installation guide | Yes |
| Cables included | Input power cable |
