RAM Mounts RAM-GDS-CHARGE-V7CU mobile device charger Black, Green, Red DC Auto

5.42-9V, USB-C, 1m

Key Features

• Hardwire charger includes USB Type-C male connection with input of 10-30VDC and output of 5.42 - 9VDC
• When upgrading devices, avoid rewiring by unplugging power connector and attaching new charger components
• Part of the GDS Ecosystem to keep devices protected, connected, and charged in nearly any application

Description

Overview

The GDS Modular Hardwire Charger is the ideal solution for providing power to any USB Type-C GDS vehicle solution. By connecting directly to the power source of your vehicle, the GDS Charger delivers up to 9V of USB Type-C power to your device. When it comes time to upgrade, avoid any rewiring by simply unplugging the power connector and attaching the new charger components. This charger does not support Power Delivery. Always Protected. Always Connected.

Specifications

Performance
Charger type	Auto
Power source type	DC
Power protection features	Over voltage, Reverse polarity, Short circuit
Certification	SAE J-1113-5, CE , FCC, UL 62368-1, E-Mark
Number of simultaneously connected devices (max)	1
Design
Product colour	Black, Green, Red
Cable length	1 m
Power
Output current	2500 mA
Input voltage	10 - 30 V
Maximum output voltage	9 V
Minimum output voltage	5.42 V
Technical details
Cables included	USB Type-C
Charger type	Auto
Power source type	DC
Power protection features	Over voltage, Reverse polarity, Short circuit
Sustainability compliance	Yes
Compliance certificates	RCM, RoHS, WEEE
Ports & interfaces
Cable length	1 m
Weight & dimensions
Weight	213 g
Packaging data
Cables included	USB Type-C
Operational conditions
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-10 - 70 °C
Packaging content
Cables included	USB Type-C
Colour
Product colour	Black, Green, Red
Certificates
Certification	SAE J-1113-5, CE , FCC, UL 62368-1, E-Mark
