Description
4 x 3.5" SATA 6Gb/s, Intel Atom x7405C, 8 GB SODIMM DDR5, 2.5 Gigabit Ethernet, 150W, 43 x 430 x 292.1 mm
Compact 1U short-depth rackmount NAS, with E1.S/M.2 PCIe NVMe slots and 10GbE expandability
The 1U short-depth rackmount TS-h765eU is designed for space-constrained environments, offering an efficient and reliable storage solution for various needs. Adopting the latest Intel® Atom x7000C Series processor, the TS-h765eU comes with four 3.5-inch drive bays and three E1.S / M.2 PCIe NVMe slots for exceptional expandability, making it an ideal NAS for high performance and multitasking demands. The TS-h765eU runs the ZFS-based QuTS hero operating system that ensures data integrity and WORM protection for data immutability.
Key Features
- Space-saving: The 1U short depth of only 292.1mm (12 inches) is suited for small media cabinets or wall-mount network racks
- DDR5 RAM: Built-in high-performance and low power consumption DDR5 RAM supports In-Band ECC (IBECC) for data reliability. Up to 16GB RAM can be installed
- Expand to two 10GbE ports: Flexibly upgrade to high-speed 10GbE by installing two E1.S to 10GbE network modules
- Dual 2.5GbE as standard: Attain faster data transfer and backup speeds by enabling Port Trunking or SMB Multichannel
- Easy storage expansion via USB: Connect a QNAP's short-depth USB JBOD TR-004U to the TS-h765eU to support up to 144 TB capacity (using 24 TB HDDs in RAID 5)
- Long-term supply: The TS-h765eU will be available and supported by QNAP for an extended period, up to 2031
Description
TS-h765eUCompact 1U short-depth rackmount NAS, with E1.S/M.2 PCIe NVMe slots and 10GbE expandability
The 1U short-depth rackmount TS-h765eU is designed for space-constrained environments, offering an efficient and reliable storage solution for various needs. Adopting the latest Intel® Atom x7000C Series processor, the TS-h765eU comes with four 3.5-inch drive bays and three E1.S / M.2 PCIe NVMe slots for exceptional expandability, making it an ideal NAS for high performance and multitasking demands. The TS-h765eU runs the ZFS-based QuTS hero operating system that ensures data integrity and WORM protection for data immutability.
Specifications
| Storage | |
|---|---|
| Online RAID migration | Yes |
| Online RAID expansion | Yes |
| Disk roaming | Yes |
| Bad block scan | Yes |
| Auto-rebuild | Yes |
| Storage drives installed | No |
| Installed storage drive type | No |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 4 |
| Hot-swap drive bays | Yes |
| RAID support | Yes |
| Supported file systems | FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
| RAID levels | 0, 1, 5, 6, 10, 50, JBOD |
| Supported storage drive interfaces | Serial ATA II, Serial ATA III |
| Storage drive sizes supported | 3.5,E1.S |
| RAID rebuild | Yes |
| Processor | |
| Processor manufacturer | Intel |
| Processor boost frequency | 3.4 GHz |
| Processor family | Intel Atom® |
| Processor cores | 4 |
| Number of processors supported | 1 |
| Memory | |
| Internal memory type | DDR5 |
| Internal memory | 8 GB |
| Maximum RAM supported | 16 GB |
| Memory slots | 1 |
| Flash memory | 8000 MB |
| Memory form factor | SO-DIMM |
| Network | |
| Dynamic DNS (DDNS) | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 100,1000,2500 Mbit/s |
| iSCSI support | Yes |
| DHCP server | Yes |
| Ports & interfaces | |
| USB port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 2.0 ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| Concurrent connections | 1500 |
| Hard drive | |
| RAID support | Yes |
| Supported file systems | FAT32, HFS+, NTFS, exFAT, ext3, ext4 |
| RAID levels | 0, 1, 5, 6, 10, 50, JBOD |
| Design | |
| Cooling type | Active |
| Fan diameter | 4 cm |
| Product colour | Black, Grey |
| Number of fans | 3 fan(s) |
| LED indicators | Yes |
| Chassis type | Rack (1U) |
| Technical details | |
| Type | NAS |
| Device class | Small & Medium Business |
| Backup function | Yes |
| Product colour | Black, Grey |
| LED indicators | Yes |
| Chassis type | Rack (1U) |
| Buzzer | Yes |
| Number of fans | 3 fan(s) |
| Performance | |
| S.M.A.R.T. support | Yes |
| Password authentication | Yes |
| Disk scan | Yes |
| Browser supported | Apple Safari, Google Chrome, Microsoft Edge, Mozilla Firefox |
| Remotely operated | Yes |
| Type | NAS |
| Device class | Small & Medium Business |
| Backup function | Yes |
| On/off switch | Yes |
| Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8 |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022 |
| Other operating systems supported | IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 11 |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Reset button | Yes |
| Operating system version | h5.2.3 |
| Operating system installed | QuTS hero |
| Buzzer | Yes |
| Snapshot | Yes |
| Cooling | |
| Cooling type | Active |
| Fan diameter | 4 cm |
| Number of fans | 3 fan(s) |
| Software | |
| Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8 |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022 |
| Other operating systems supported | IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 11 |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Operating system version | h5.2.3 |
| Operating system installed | QuTS hero |
| Management features | |
| On/off switch | Yes |
| Reset button | Yes |
| Power | |
| Power supply location | Built-in |
| Power supply unit (PSU) capacity | 150 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Number of power supply units | 1 |
| Weight & dimensions | |
| Width | 430 mm |
| Depth | 292.1 mm |
| Height | 43 mm |
| Weight | 4.51 kg |
| Packaging content | |
| Cables included | AC |
| System requirements | |
| Windows operating systems supported | Windows 10, Windows 11, Windows 7, Windows 8 |
| Server operating systems supported | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022 |
| Other operating systems supported | IBM AIX 7.1, IBM AIX 7.2, Solaris 10, Solaris 11 |
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Operational conditions | |
| Storage temperature (T-T) | 20 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Packaging data | |
| Cables included | AC |
