Description
1920 x 1080 px, 60 Hz, USB Power 2 x USB A, DisplayPort 1.2, RJ45, 55 x 25 x 110 mm, 0.2 kg
With DisplayPort video and USB2.0 for keyboard, mouse and other HID devices. Unlike remote access software it operates out-of-band, enabling BIOS control of the target PC during boot and securely separating remote users from the local network.
ARDx Enabled
ADDERLink Portal is ARDx enabled and therefore requires ARDx Viewer (download from the ARDx Viewer product page), which provides a seamless user experience and powerful admin tools for managing connections and users.
High quality audio and video
Experience exceptional media streaming with HD 1920x1080 resolution at ultra-smooth 60Hz frame rates, 4:4:4 accurate color and 16-bit 44.1kHz PCM stereo audio. Fluid motion, pure color and clear text reproduction for image critical applications.
Seamless User Experience
Inherently low latency provides precision control as though you are operating the host PC directly. On a network with suitable capacity, up to eight users can access concurrently without performance degradation.
Highly Secure
Enterprise-grade security ensures your connection is safe. AES-256 encryption and RSA-2048 authentication offer the highest level of protection, trusted by security agencies and financial institutions worldwide.
Network Capability
For critical performance applications, ADDERLink Portal is optimized for use over a Local Area Network (LAN). Wide Area Network (WAN) connectivity for remote internet access can be achieved through a firewall port or Virtual Private Network (VPN).
Simple Installation
The Zero U dongle form factor requires no rack space. USB power from the host PC means no bulky power supply or spare wall socket is required although an external supply can be used.
Target any OS
Unlike remote access via software, the ADDERLink Portal can control any PC with a KVM connection, regardless of the Operating System. Advantageous for installations where the OS may be considered legacy, or configuration change is prohibited.
Description
Hardware remote KVMWith DisplayPort video and USB2.0 for keyboard, mouse and other HID devices. Unlike remote access software it operates out-of-band, enabling BIOS control of the target PC during boot and securely separating remote users from the local network.
ARDx Enabled
ADDERLink Portal is ARDx enabled and therefore requires ARDx Viewer (download from the ARDx Viewer product page), which provides a seamless user experience and powerful admin tools for managing connections and users.
High quality audio and video
Experience exceptional media streaming with HD 1920x1080 resolution at ultra-smooth 60Hz frame rates, 4:4:4 accurate color and 16-bit 44.1kHz PCM stereo audio. Fluid motion, pure color and clear text reproduction for image critical applications.
Seamless User Experience
Inherently low latency provides precision control as though you are operating the host PC directly. On a network with suitable capacity, up to eight users can access concurrently without performance degradation.
Highly Secure
Enterprise-grade security ensures your connection is safe. AES-256 encryption and RSA-2048 authentication offer the highest level of protection, trusted by security agencies and financial institutions worldwide.
Network Capability
For critical performance applications, ADDERLink Portal is optimized for use over a Local Area Network (LAN). Wide Area Network (WAN) connectivity for remote internet access can be achieved through a firewall port or Virtual Private Network (VPN).
Simple Installation
The Zero U dongle form factor requires no rack space. USB power from the host PC means no bulky power supply or spare wall socket is required although an external supply can be used.
Target any OS
Unlike remote access via software, the ADDERLink Portal can control any PC with a KVM connection, regardless of the Operating System. Advantageous for installations where the OS may be considered legacy, or configuration change is prohibited.
Specifications
| Ports & interfaces | |
|---|---|
| Console ports | RJ–45 |
| USB connector type | USB Type-A |
| DisplayPort version | 1.2 |
| Video port type | DisplayPort |
| Audio connections | Yes |
| DC-in jack | Yes |
| USB 2.0 Type-A hub ports quantity | 2 |
| Cable length | 0.3 m |
| Ethernet LAN (RJ-45) ports | 1 |
| Network | |
| Ethernet LAN | Yes |
| Security algorithms | 256-bit AES |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance | |
| HD type | Full HD |
| Video bandwidth | 60 Hz |
| Maximum resolution | 1920 x 1080 pixels |
| Audio channels | 2.0 |
| Security algorithms | 256-bit AES |
| Technical details | |
| Product colour | Black |
| LED indicators | Yes |
| Compliance certificates | ANSI, China RoHS, Federal Communications Commission (FCC) |
| Design | |
| Product colour | Black |
| Cable length | 0.3 m |
| LED indicators | Yes |
| Housing material | Acrylonitrile butadiene styrene (ABS), Aluminium |
| Display | |
| Built-in display | No |
| Power | |
| Power source | USB |
| Power consumption (typical) | 3 W |
| External power adapter | Yes |
| Video | |
| HD type | Full HD |
| Video bandwidth | 60 Hz |
| Maximum resolution | 1920 x 1080 pixels |
| Security | |
| Security algorithms | 256-bit AES |
| Sustainability | |
| Compliance certificates | ANSI, China RoHS, Federal Communications Commission (FCC) |
| Weight & dimensions | |
| Width | 55 mm |
| Depth | 110 mm |
| Height | 25 mm |
| Weight | 200 g |
| Package width | 245 mm |
| Package depth | 55 mm |
| Package height | 292 mm |
| Package weight | 500 g |
| Packaging data | |
| Package width | 245 mm |
| Package depth | 55 mm |
| Package height | 292 mm |
| Package weight | 500 g |
