ALTHEA21W65 3-Port 65W GaN USB PD Charger, USB-C x 2, USB-A x 1, QC 3.0, PPS, PD 3.0
Key Features
- High-Power GaN Technology: This charger utilizes advanced Gallium Nitride (GaN) technology, providing up to 65W of total power for faster and more efficient charging.
- Versatile Port Selection: Equipped with 3 ports including 2 USB-C ports (with PD 3.0) and 1 USB-A ports (with QC 3.0), allowing simultaneous charging for multiple devices with varying power requirements.
- Wide Compatibility: Supports a range of output options from 3.3V to 20.0V across its ports, ensuring compatibility with devices from smartphones to laptops.
- Enhanced Safety Features: Built-in protections against overload, short circuiting, and overheating, ensuring the safety of both the charger and connected devices.
- Efficiency and Fast Charging Technology: Incorporates USB Power Delivery (PD) 3.0 and Quick Charge (QC) 3.0 technologies for rapid charging, along with Programmable Power Supply (PPS) compliance to maximize charging efficiency and minimize heat generation.
Description
This charger features cutting-edge Gallium Nitride (GaN) technology, delivering up to 65W of total power for faster and more efficient charging. It includes 3 versatile ports: 2 USB-C ports with USB Power Delivery (PD) 3.0 and 1 USB-A port with Quick Charge (QC) 3.0, allowing you to charge multiple devices simultaneously with varying power requirements. The charger supports output options ranging from 3.3V to 20.0V across its ports, ensuring broad compatibility with devices from smartphones to laptops. Enhanced safety features protect against overload, short circuiting, and overheating, safeguarding both the charger and connected devices. Additionally, it incorporates USB PD 3.0 and QC 3.0 technologies, along with Programmable Power Supply (PPS) compliance to maximize charging efficiency and minimize heat.
Specifications
| Performance |
|---|
| Country of origin |
China |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| Charger type |
Indoor |
| Charger compatibility |
Universal |
| Power source type |
AC |
| Power protection features |
Overheating, Overload, Short circuit |
| Fast charging |
Yes |
| Fast charging technology |
Power Delivery 3.0, Programmable Power Supply (PPS), Quick Charge 3.0 |
| USB Type-C ports quantity |
2 |
| USB Power Delivery (USB PD) |
Yes |
| USB Power Delivery revision |
3.0 |
| Programmable power supply (PPS) |
Yes |
| Number of simultaneously connected devices (max) |
3 |
| Design |
|---|
| Product colour |
White |
| Cable length |
1.5 m |
| Gallium nitride (GaN) transistors |
Yes |
| Housing material |
Polycarbonate (PC) |
| Power |
|---|
| Port 2 output current |
4.5 A |
| Port 1 output current |
4.5 A |
| Input current |
1.5 A |
| Maximum power |
65 W |
| Input voltage |
100 - 240 V |
| Input frequency |
50 - 60 Hz |
| Maximum output voltage |
20 V |
| Minimum output voltage |
3.3 V |
| Port 3 output current |
3 A |
| Technical details |
|---|
| Package type |
Hanging box |
| Cables included |
USB Type-C to USB Type-C |
| Charger type |
Indoor |
| Charger compatibility |
Universal |
| Power source type |
AC |
| Power protection features |
Overheating, Overload, Short circuit |
| Country of origin |
China |
| Manual |
Yes |
| Harmonized System (HS) code |
850440 |
| Compliance certificates |
CE, RoHS |
| Master (outer) cases per pallet |
32 pc(s) |
| Ports & interfaces |
|---|
| Cable length |
1.5 m |
| Weight & dimensions |
|---|
| Width |
57 mm |
| Depth |
51 mm |
| Height |
32 mm |
| Weight |
129.6 g |
| Package width |
127 mm |
| Package depth |
84 mm |
| Package height |
35 mm |
| Package weight |
177.6 g |
| Packaging data |
|---|
| Package type |
Hanging box |
| Cables included |
USB Type-C to USB Type-C |
| Package width |
127 mm |
| Package depth |
84 mm |
| Package height |
35 mm |
| Package weight |
177.6 g |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-20 - 80 °C |
| Storage relative humidity (H-H) |
10 - 90% |
| Operating temperature (T-T) |
0 - 40 °C |
| Packaging content |
|---|
| Manual |
Yes |
| Cables included |
USB Type-C to USB Type-C |
| Package type |
Hanging box |
| Certificates |
|---|
| Compliance certificates |
CE, RoHS |
| Colour |
|---|
| Product colour |
White |
| Logistics data |
|---|
| Country of origin |
China |
| Products per master (outer) case |
80 pc(s) |
| Master (outer) case width |
385 mm |
| Master (outer) case length |
272 mm |
| Master (outer) case height |
360 mm |
| Master (outer) case gross weight |
14.9 kg |
| Pallet gross width |
120 cm |
| Pallet gross length |
80 cm |
| Pallet gross height |
159.2 cm |
| Customs product code (TARIC) |
8504408390 |
| Harmonized System (HS) code |
850440 |
| Other features |
|---|
| Country of origin |
China |
| Manual |
Yes |
| Package type |
Hanging box |
