Description
Lightfinder 2.0, CMOS 1/1.2", 3840x2160, 5.9 - 13.3 / 15.2 - 48.7 mm
Superior image quality
AXIS Q1728 offers 4K resolution at 60 fps and features a large 1/1.2" sensor to ensure consistent performance even in low light. Thanks to Lightfinder 2.0 and Forensic WDR, it delivers true colors and great forensic detail in challenging light or near darkness. Axis Zipstream with support for AV1, H.264, and H.265 significantly lowers bandwidth and storage requirements. What’s more, it’s available in two variants with a choice of lenses: a wide (6-13 mm) lens with a 108°-49° horizontal field of view for surveillance in wide, open areas, and a tele (15-48 mm) lens with a 42°-13° horizontal field of view for great detail at long distances. Plus, the built-in lens with remote zoom and focus is perfectly calibrated to save you time and effort.
Flexible today and tomorrow
With the flexibility to use various types of enclosures, this compact and lightweight camera with integrated optics helps ensure you preserve the value of your investment. That’s because it has a standardized design that can fit into most enclosures including Axis, third-party housing, and custom enclosures. It’s also backward compatible so you can mount it in your existing outdoor enclosure. Plus, this future-proof camera can also be mounted in new enclosures ensuring you have the flexibility to respond to future requirements.
ARTPEC-9 for unmatched performance
ARTPEC-9 refines the remarkable features and capabilities that characterized previous generations of our in-house-designed SoC: low bitrate, AI-powered analytics, superior imaging, and built-in cybersecurity. It also introduces AV1, an open-source video encoding standard from the Alliance for Open Media. With support for AV1 and enhanced image processing, ARTPEC-9 delivers high-quality video with uncompromised detail and clarity, and best-in-class bitrate. Together with Axis Zipstream, AV1 also ensures hassle-free video both on-prem and in the cloud. What’s more, ARTPEC-9 powers advanced analytics applications that detect objects earlier and analyze events more precisely.
Powerful with strong security
Featuring a deep learning processing unit (DLPU), this AI-based camera lets you run advanced features and powerful analytics on the edge. It comes with AXIS Object Analytics preinstalled to detect, classify, track, and count humans, vehicles, and types of vehicles. With AXIS Image Health Analytics preinstalled, you’ll be notified if your image is blocked, degraded, under exposed, or redirected. In addition, AXIS Live Privacy Shield address-es privacy laws and regulations and offers AI-based dynamic masking so you can detect movement and activities while safeguarding privacy. Furthermore, Axis Edge Vault, a hardware-based cybersecurity plat-form, safeguards the device and offers FIPS 140-3 Level 3 certified secure key storage and operations.
Key Features
- Superior image quality in 4K
- Designed to fit into most enclosures
- Next-generation AI-powered analytics
- Wide or tele lenses available
- Built-in cybersecurity with Axis Edge Vault
Description
Built on ARTPEC-9, this AI-powered block camera offers accelerated performance and lets you run impressive analytics applications on the edge. It’s possible to use your existing housing or upgrade to new housing, making it a more environmentally friendly option.Superior image quality
AXIS Q1728 offers 4K resolution at 60 fps and features a large 1/1.2" sensor to ensure consistent performance even in low light. Thanks to Lightfinder 2.0 and Forensic WDR, it delivers true colors and great forensic detail in challenging light or near darkness. Axis Zipstream with support for AV1, H.264, and H.265 significantly lowers bandwidth and storage requirements. What’s more, it’s available in two variants with a choice of lenses: a wide (6-13 mm) lens with a 108°-49° horizontal field of view for surveillance in wide, open areas, and a tele (15-48 mm) lens with a 42°-13° horizontal field of view for great detail at long distances. Plus, the built-in lens with remote zoom and focus is perfectly calibrated to save you time and effort.
Flexible today and tomorrow
With the flexibility to use various types of enclosures, this compact and lightweight camera with integrated optics helps ensure you preserve the value of your investment. That’s because it has a standardized design that can fit into most enclosures including Axis, third-party housing, and custom enclosures. It’s also backward compatible so you can mount it in your existing outdoor enclosure. Plus, this future-proof camera can also be mounted in new enclosures ensuring you have the flexibility to respond to future requirements.
ARTPEC-9 for unmatched performance
ARTPEC-9 refines the remarkable features and capabilities that characterized previous generations of our in-house-designed SoC: low bitrate, AI-powered analytics, superior imaging, and built-in cybersecurity. It also introduces AV1, an open-source video encoding standard from the Alliance for Open Media. With support for AV1 and enhanced image processing, ARTPEC-9 delivers high-quality video with uncompromised detail and clarity, and best-in-class bitrate. Together with Axis Zipstream, AV1 also ensures hassle-free video both on-prem and in the cloud. What’s more, ARTPEC-9 powers advanced analytics applications that detect objects earlier and analyze events more precisely.
Powerful with strong security
Featuring a deep learning processing unit (DLPU), this AI-based camera lets you run advanced features and powerful analytics on the edge. It comes with AXIS Object Analytics preinstalled to detect, classify, track, and count humans, vehicles, and types of vehicles. With AXIS Image Health Analytics preinstalled, you’ll be notified if your image is blocked, degraded, under exposed, or redirected. In addition, AXIS Live Privacy Shield address-es privacy laws and regulations and offers AI-based dynamic masking so you can detect movement and activities while safeguarding privacy. Furthermore, Axis Edge Vault, a hardware-based cybersecurity plat-form, safeguards the device and offers FIPS 140-3 Level 3 certified secure key storage and operations.
Specifications
| Performance | |
|---|---|
| PTZ modes | Digital PTZ |
| Type | IP security camera |
| PTZ control | Yes |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Luminous flux | 0.05 lm |
| Design | |
| Form factor | Box |
| Product colour | Black |
| Mounting type | Pole clamp |
| Housing material | Aluminium, Plastic |
| Camera | |
| Camera shutter speed | 1/66500 s |
| Camera pixel size | 2.9 µm |
| Image sensor | |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 1.2 mm (1 / 1.2") |
| Lens system | |
| Number of lenses | 1 |
| Auto focus | Yes |
| Normal focusing range | 0.5 m |
| Lens diameter | 1.3 cm |
| Night vision | |
| Night vision | Yes |
| Video | |
| Noise reduction | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Gain control type | Auto |
| Bit rate control | Variable Bit Rate (VBR) |
| Noise reduction technology | 2D noise reduction, 3D noise reduction |
| Maximum resolution | 3840 x 2160 pixels |
| Video formats supported | AV1, H.264, H.265, M-JPEG |
| Supported graphics resolutions | 2560 x 1600 (WQXGA), 2592 x 1944, 3840 x 2160 |
| Frame rate | 60 fps |
| Video streaming | Yes |
| Audio | |
| Signal-to-Noise Ratio (SNR) | 55 dB |
| Audio formats supported | AAC-LC, ADPCM, G.711, G.726, LPCM, OPUS |
| Network | |
| Ethernet LAN | Yes |
| Supported network protocols | IPv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPSb , HTTP/2, TLSc , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP® , SNMP v1/v2c/v3 (MIB-II), DNS/DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP/RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/v6, ARP, SSH, LLDP, CDP, MQTT v3.1.1, Secure syslog (RFC 3164/5424, UDP/TCP/TLS), Link-Local address (ZeroConf) |
| Storage | |
| Card reader integrated | Yes |
| Built-in HDD | Yes |
| HDD capacity | 4 GB |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 8000 MB |
| Ports & interfaces | |
| RS-485 ports | 1 |
| RS-422 ports | 1 |
| Headphone outputs | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
| Security algorithms | EAP-TLS, HTTPS, PEAP, TLS |
| Power | |
| Power source type | DC |
| Power consumption (max) | 12.95 W |
| Power consumption (typical) | 7.5 W |
| DC output voltage | 10, 12, 15, 16, 24, 28 |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 60 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Weight | 529 g |
| Packaging content | |
| Number of cameras | 1 |
